Wind Top AE2400-009FR
Model Wind Top AE2400-009FRPart no. 9S6-AE1111-009EAN 4719072165178
67 specifications
- Display59.9 cm (23.6")
- Resolution1920 x 1080 pixels
- ProcessorIntel® Core™2 Quad
- Memory4 GB
- Storage1 TB
- GraphicsAMD Mobility Radeon HD 565v
Overview
- Display
- 59.9 cm (23.6")
- Resolution
- 1920 x 1080 pixels
- Processor
- Intel® Core™2 Quad
- Memory
- 4 GB
- Storage
- 1 TB
- Graphics
- AMD Mobility Radeon HD 565v
- Brand
- MSI
- Category
- All-in-One PCs/Workstations
- Model
- Wind Top AE2400-009FR
- Part number
- 9S6-AE1111-009
- EAN / UPC
- 4719072165178
- Also known as
- MSI Wind Top AE2400-009FR Intel® Core™2 Quad 59.9 cm (23.6") 1920 x 1080 pixels Touchscreen 4 GB DDR3-SDRAM 1 TB AMD Mobility Radeon HD 565v Windows 7 Home Prem
Specifications
67 specifications in 15 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 59.9 cm (23.6") |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | Yes |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™2 Quad |
| Processor cores | 4 |
| Processor frequency | 2.66 GHz |
| Processor cache | 6 MB |
| Processor cache type | L2 |
| Processor front side bus | 1333 MHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR3-SDRAM |
| Maximum internal memory | 8 GB |
| Memory slots | 2 |
| Memory layout (slots x size) | 2 x 2 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1 TB |
| HDD interface | SATA |
| Optical drive type | DVD Super Multi |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | AMD Mobility Radeon HD 565v |
| Discrete graphics memory type | GDDR3 |
| On-board graphics card | No |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Firewire (IEEE 1394) ports | 0 |
| PS/2 ports quantity | 0 |
| Serial ports quantity | 0 |
| eSATA ports quantity | 1 |
| S/PDIF out port | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® G41 Express |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Home Premium |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 577 mm |
| Depth (with stand) | 73 mm |
| Height (with stand) | 445 mm |
| Weight (with stand) | 11.6 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
| Keyboard included | Yes |
| Remote control included | Yes |
Other features
| Specification | Value |
|---|---|
| Graphics card family | AMD |
| Audio output channels | 5.1 channels |
| Cabling technology | 10/100/1000 Base-T(X) |
| Chassis type | All-in-One |
| Display | Full HD |
| Display included | Yes |
| Floppy drive installed | No |
| Maximum graphics card memory | 1024 MB |
| Networking features | Gigabit Ethernet, WLAN |
| Number of processors installed | 1 |
| Parallel ports quantity | 0 |
| Power supply | 180 W |
| Speakers | 2 x 5W + 10W |
| TV tuner integrated | No |
| Expansion slots | Mini PCI-E x 2 |
