Wind Top AE2060
Model Wind Top AE2060Part no. AE2060-021ITEAN 4719072220112
115 specifications
- Display50.8 cm (20")
- Resolution1366 x 768 pixels
- ProcessorIntel® Pentium®
- Memory4 GB
- Storage500 GB
- OSWindows 7 Professional
Overview
- Display
- 50.8 cm (20")
- Resolution
- 1366 x 768 pixels
- Processor
- Intel® Pentium®
- Memory
- 4 GB
- Storage
- 500 GB
- OS
- Windows 7 Professional
- Brand
- MSI
- Category
- All-in-One PCs/Workstations
- Model
- Wind Top AE2060
- Part numbers
- AE2060-021IT, 9S6-AA5112-021
- EAN / UPC
- 4719072220112
- Also known as
- MSI Wind Top AE2060 Intel® Pentium® E5800 50.8 cm (20") 1366 x 768 pixels 4 GB DDR3-SDRAM 500 GB Windows 7 Professional White
Specifications
115 specifications in 14 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 50.8 cm (20") |
| Display resolution | 1366 x 768 pixels |
| HD type | Not supported |
| Native aspect ratio | 16:9 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Pentium® |
| Processor model | E5800 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 3.2 GHz |
| Processor cache | 2 MB |
| Processor cache type | Smart Cache |
| Processor socket | LGA 775 (Socket T) |
| Thermal Design Power (TDP) | 65 W |
| Bus type | FSB |
| CPU multiplier (bus/core ratio) | 16 |
| FSB Parity | No |
| Number of Processing Die Transistors | 228 M |
| Processing Die size | 82 mm² |
| Processor code | SLGTG |
| Processor codename | Wolfdale |
| Processor front side bus | 800 MHz |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Pentium E5000 Series for Desktop |
| Stepping | R0 |
| Tcase | 74.1 °C |
| Conflict-Free processor | No |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR3-SDRAM |
| Maximum internal memory | 8 GB |
| Memory clock speed | 1066 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| HDD size | 3.5" |
| HDD interface | SATA II |
| Optical drive type | DVD-RW |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card family | Intel® GMA |
| On-board graphics card model | Intel® GMA X4500 |
Audio
| Specification | Value |
|---|---|
| Number of speakers | 2 |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Firewire (IEEE 1394) ports | 0 |
| Mini PCI Express slots | 2 |
| PS/2 ports quantity | 0 |
| Serial ports quantity | 0 |
Design
| Specification | Value |
|---|---|
| Product colour | White |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Professional |
| Operating system architecture | 64-bit |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® Turbo Boost Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 42802 |
| Processor package size | 37.5 x 37.5 mm |
| Thermal Monitoring Technologies | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 513.2 mm |
| Depth (with stand) | 87.7 mm |
| Height (with stand) | 392.1 mm |
Other features
| Specification | Value |
|---|---|
| Graphics card family | Intel |
| Cabling technology | 10/100/1000Base-T(X) |
| Chassis type | All-in-One |
| Compatible operating systems | Windows 7 |
| Compliance industry standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Dimensions (WxDxH) | 513.2 x 87.7 x 392.1 mm |
| Display | LCD |
| Display included | Yes |
| Mac compatibility | No |
| Megapixel (approx.) | 0.3 MP |
| Motherboard southbridge | Intel ICH7 |
| Networking features | Gigabit Ethernet |
| Number of processors installed | 1 |
| Parallel ports quantity | 0 |
| Platform | PC |
| Speakers | monitor built-in |
