AM272P 1M
Model AM272P 1MPart no. 00-AF8231-886EAN 4711377246644
73 specifications
- Display68.6 cm (27")
- Resolution1920 x 1080 pixels
- ProcessorIntel Core 7
- Memory16 GB
- Storage512 GB
- SpeedWi-Fi 6E (802.11ax)
Overview
- Display
- 68.6 cm (27")
- Resolution
- 1920 x 1080 pixels
- Processor
- Intel Core 7
- Memory
- 16 GB
- Storage
- 512 GB
- Speed
- Wi-Fi 6E (802.11ax)
- Brand
- MSI
- Category
- All-in-One PCs/Workstations
- Model
- AM272P 1M
- Part number
- 00-AF8231-886
- EAN / UPC
- 4711377246644
- Also known as
- MSI AM272P 1M Intel Core 7 150U 68.6 cm (27") 1920 x 1080 pixels All-in-One PC 16 GB DDR5-SDRAM 512 GB SSD Wi-Fi 6E (802.11ax) Black
Specifications
73 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Display brightness | 300 cd/m² |
| Panel type | IPS |
| Response time | 14 ms |
| Anti-glare screen | Yes |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Tilt adjustment | Yes |
| Tilt angle range | -4 - 20° |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core 7 |
| Processor model | 150U |
| Processor cores | 10 |
| Processor threads | 12 |
| Processor boost frequency | 5.4 GHz |
| Processor frequency | 1.8 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 64 GB |
| Memory slots | 2 |
| Memory slots type | SO-DIMM |
| Memory clock speed | 2800 MHz |
| Memory layout (slots x size) | 2 x 8 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 512 GB |
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | M.2, PCI Express 4.0 |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| On-board GPU manufacturer | Intel |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card model | Intel® Graphics |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Audio chip | Realtek ALC256 |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
| Total megapixels | 2 MP |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Realtek |
| WLAN controller model | Realtek RTL8111H |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | No |
Performance
| Specification | Value |
|---|---|
| Product type | All-in-One PC |
| Motherboard chipset | Intel SoC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 611.8 mm |
| Depth (with stand) | 194.7 mm |
| Height (with stand) | 561.5 mm |
| Weight (with stand) | 7.5 kg |
| Package weight | 9.85 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse connectivity | Wireless |
| Mouse included | Yes |
| Keyboard connectivity | Wireless |
| Keyboard included | Yes |
