MSI AE200 5M-WE26114G50S7VGMXH

Model AE200 5M-WE26114G50S7VGMXHPart no. 00AA8112-SKU6PEAN 4053162937680

91 specifications

Display49.5 cm (19.5")
Resolution1600 x 900 pixels
ProcessorAMD E
Memory4 GB
Storage500 GB
GraphicsNot available

See all specifications

Overview

Display: 49.5 cm (19.5")
Resolution: 1600 x 900 pixels
Processor: AMD E
Memory: 4 GB
Storage: 500 GB
Graphics: Not available

Brand: MSI
Category: All-in-One PCs/Workstations
Model: AE200 5M-WE26114G50S7VGMXH
Part number: 00AA8112-SKU6P
EAN / UPC: 4053162937680, 4719072408800
Also known as: MSI Wind Top AE200 5M-WE26114G50S7VGMXH AMD E E2-6110 49.5 cm (19.5") 1600 x 900 pixels Touchscreen All-in-One PC 4 GB DDR3-SDRAM 500 GB HDD Windows 7 Professio

Specifications

91 specifications in 18 groups

Display

Specification	Value
Display diagonal	49.5 cm (19.5")
Display resolution	1600 x 900 pixels
Touchscreen	Yes
HD type	HD+
LED backlight	Yes
Native aspect ratio	16:9
Display brightness	250 cd/m²
Response time	5 ms
Display number of colours	16.78 million colours
Pixel pitch	0.2768 x 0.2768 mm
Screen shape	Flat

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD E
Processor model	E2-6110
Processor cores	4
Processor threads	4
Processor frequency	1.5 GHz
Processor cache	2 MB
Processor cache type	L2
Processor socket	Socket FT3b
Thermal Design Power (TDP)	15 W
PCI Express slots version	2.0
Processor lithography	28 nm

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	1333 MHz
Memory layout (slots x size)	1 x 4 GB

Storage

Specification	Value
Total storage capacity	500 GB
Storage media	HDD
Number of HDDs installed	1
HDD capacity	500 GB
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Compatible memory cards	MMC, Memory Stick (MS), SD, xD

Graphics

Specification	Value
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card family	AMD Radeon R3
On-board graphics card model	AMD Radeon R3

Audio

Specification	Value
Built-in speaker(s)	Yes
RMS rated power	3 W
Built-in microphone	Yes
Audio chip	Realtek ALC887
Audio system	SRS Premium Sound

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	1 MP

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
Thunderbolt ports quantity	0
HDMI ports quantity	1
VGA (D-Sub) ports quantity	0
Headphone outputs	1
Microphone in	Yes
Combo headphone/mic port	Yes
Mini PCI Express slots	2
Serial ports quantity	1

Design

Specification	Value
Product colour	White
Cable lock slot	Yes
Cable lock slot type	Kensington
Wall mountable	Yes

Performance

Specification	Value
Product type	All-in-One PC

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit

Power

Specification	Value
AC adapter power	65 W

Weight & dimensions

Specification	Value
Width (with stand)	513 mm
Depth (with stand)	92 mm
Height (with stand)	392 mm
Weight (with stand)	6.81 kg

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-20 - 60 °C

Certificates

Specification	Value
Certification	UL/CB, EMC:CE/FCC/C-TICK/VCCI/BSMI

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Other features

Specification	Value
3D	No
Autonomy mode	No
Detachable display	No
