MSI 20EXTS 8GL-013XES

Model 20EXTS 8GL-013XESPart no. 9S6-AAC212-013EAN 4719072590109

135 specifications

Display49.5 cm (19.5")
Resolution1600 x 900 pixels
ProcessorIntel® Celeron®
Memory4 GB
Storage128 GB
GraphicsNot available

See all specifications

Overview

Display: 49.5 cm (19.5")
Resolution: 1600 x 900 pixels
Processor: Intel® Celeron®
Memory: 4 GB
Storage: 128 GB
Graphics: Not available

Brand: MSI
Category: All-in-One PCs/Workstations
Model: 20EXTS 8GL-013XES
Part number: 9S6-AAC212-013
EAN / UPC: 4719072590109
Also known as: MSI Pro 20EXTS 8GL-013XES Intel® Celeron® N4000 49.5 cm (19.5") 1600 x 900 pixels All-in-One PC 4 GB DDR4-SDRAM 128 GB SSD Wi-Fi 5 (802.11ac) White

Specifications

135 specifications in 21 groups

Display

Specification	Value
Display diagonal	49.5 cm (19.5")
Display resolution	1600 x 900 pixels
Touchscreen	No
HD type	4K Ultra HD
LED backlight	No
Display brightness	250 cd/m²
Panel type	LCD
Response time	5 ms
Display number of colours	16.78 million colours
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	N4000
Processor cores	2
Processor threads	2
Processor boost frequency	2.6 GHz
Processor frequency	1.1 GHz
Processor cache	4 MB
Processor socket	BGA 1090
Thermal Design Power (TDP)	6 W
Maximum number of PCI Express lanes	6
PCI Express configurations	1x2, 1x2+2x1, 1x4, 2x1, 4x1
PCI Express slots version	2.0
Processor codename	Gemini Lake
Processor lithography	14 nm
Processor operating modes	64-bit
Scenario Design Power (SDP)	4.8 W
Tjunction	105 °C
Conflict-Free processor	Yes
Maximum internal memory supported by processor	8 GB
Memory types supported by processor	DDR4-SDRAM, LPDDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	2400 MHz
Memory layout (slots x size)	1 x 4 GB

Storage

Specification	Value
Total storage capacity	128 GB
Storage media	SSD
Number of SSDs installed	1
SSD capacity	128 GB
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Compatible memory cards	MMC, SD

Graphics

Specification	Value
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics 600
Maximum on-board graphics card memory	8 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	650 MHz
On-board graphics card dynamic frequency (max)	650 MHz
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x3185
Number of execution units	12

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	10 W

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	1 MP

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 3168
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
Thunderbolt ports quantity	0
HDMI ports quantity	1
VGA (D-Sub) ports quantity	1
Headphone outputs	1
Microphone in	Yes
Combo headphone/mic port	Yes
DC-in jack	Yes

Design

Specification	Value
Product colour	White
Panel mounting interface	100 x 100 mm
VESA mounting	Yes
On/off button	Yes

Performance

Specification	Value
Product type	All-in-One PC

Software

Specification	Value
Operating system installed	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Smart Response Technology version	0.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	128988
Processor package size	25 x 24 mm
Thermal Monitoring Technologies	Yes
UART	Yes

Power

Specification	Value
AC adapter power	120 W

Pen

Specification	Value
Pen included	No

Weight & dimensions

Specification	Value
Width (with stand)	399.5 mm
Depth (with stand)	69.2 mm
Height (with stand)	313.9 mm
Weight (with stand)	5.6 kg
Package weight	6.49 kg

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-20 - 60 °C

Certificates

Specification	Value
Certification	UL/CB , EMC:CE/FCC/C TICK/VCCI/BSMI

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Other features

Specification	Value
3D	No
Detachable display	No
