MEDION AKOYA E23201
MEDION

AKOYA E23201

Model AKOYA E23201Part no. 30025720EAN 4061275050288

106 specifications
  • Display60.5 cm (23.8")
  • ProcessorIntel® Celeron®
  • Memory4 GB
  • Storage1 TB
  • GraphicsNot available
  • SpeedWi-Fi 5 (802.11ac)
See all specifications

Overview

Display
60.5 cm (23.8")
Processor
Intel® Celeron®
Memory
4 GB
Storage
1 TB
Graphics
Not available
Speed
Wi-Fi 5 (802.11ac)
Brand
MEDION
Model
AKOYA E23201
Part number
30025720
EAN / UPC
4061275050288
Also known as
MEDION AKOYA E23201 Intel® Celeron® J4005 60.5 cm (23.8") All-in-One PC 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.11ac) Silver

Specifications

106 specifications in 15 groups

Display

Display diagonal60.5 cm (23.8")
TouchscreenNo
LED backlightYes
Screen shapeFlat

Processor

Processor manufacturerIntel
Processor familyIntel® Celeron®
Processor modelJ4005
Processor cores2
Processor threads2
Processor boost frequency2.7 GHz
Processor frequency2 GHz
Processor cache4 MB
Processor socketBGA 1090
Thermal Design Power (TDP)10 W
Maximum number of PCI Express lanes6
PCI Express configurations1x2, 1x2+2x1, 1x4, 2x1, 4x1
PCI Express slots version2.0
Processor codenameGemini Lake
Processor lithography14 nm
Processor operating modes64-bit
Tjunction105 °C
Conflict-Free processorYes
Maximum internal memory supported by processor8 GB
Memory types supported by processorDDR4-SDRAM, LPDDR4-SDRAM
Memory clock speeds supported by processor2400 MHz
Memory channels supported by processorDual
ECC supported by processorNo

Memory

Internal memory4 GB
Internal memory typeDDR4-SDRAM

Storage

Total storage capacity1 TB
Storage mediaHDD
Total HDDs capacity1 TB
Number of HDDs installed1
HDD capacity1 TB
HDD size2.5"

Graphics

Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics cardYes
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel® UHD Graphics 600
Maximum on-board graphics card memory8 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency250 MHz
On-board graphics card burst frequency700 MHz
On-board graphics card dynamic frequency (max)700 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x3185
Number of execution units12

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN controller modelIntel Dual Band Wireless-AC 3168
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
BluetoothYes
Bluetooth version4.2

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
HDMI ports quantity1
HDMI version1.4
Headphone outputs1
Microphone inYes

Design

Product colourSilver

Performance

Product typeAll-in-One PC

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Enhanced Halt StateYes
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Smart Response Technology version0.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Anti-Theft Technology (Intel® AT)No
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Smart Response TechnologyNo
Intel® Turbo Boost TechnologyNo
Processor ARK ID128992
Processor package size25 x 24 mm
Thermal Monitoring TechnologiesYes
UARTYes

Power

AC adapter power65 W

Weight & dimensions

Width (with stand)546 mm
Depth (with stand)120 mm
Height (with stand)386 mm
Weight (with stand)3 kg

Packaging content

Mouse includedYes
Keyboard includedYes
AC adapter includedYes
Power cord includedYes
ManualYes

Other features

3DNo
Detachable displayNo
