Lenovo AIO 7 27ACH6

AIO 7 27ACH6

Model AIO 7 27ACH6Part no. F0G7002BRKEAN 196380853197

96 specifications

Display68.6 cm (27")
Resolution3840 x 2160 pixels
ProcessorAMD Ryzen™ 7
Memory16 GB
Storage1 TB
GraphicsAMD Radeon RX 6600M

See all specifications

Overview

Display: 68.6 cm (27")
Resolution: 3840 x 2160 pixels
Processor: AMD Ryzen™ 7
Memory: 16 GB
Storage: 1 TB
Graphics: AMD Radeon RX 6600M

Brand: Lenovo
Category: All-in-One PCs/Workstations
Model: AIO 7 27ACH6
Part numbers: F0G7002BRK, F0G70041UK, F0G7003VUK, F0G7004DSP, F0G7004YUK, F0G70050UK +28 more
EAN / UPC: 196380853197, 196119741153, 196119639429, 196378009216 +30 more
Also known as: Lenovo Yoga AIO 7 27ACH6 AMD Ryzen™ 7 5800H 68.6 cm (27") 3840 x 2160 pixels All-in-One PC 16 GB DDR4-SDRAM 1 TB SSD AMD Radeon RX 6600M Windows 11 Home Wi-Fi 6

Specifications

96 specifications in 19 groups

Display

Specification	Value
Display diagonal	68.6 cm (27")
Display resolution	3840 x 2160 pixels
Touchscreen	No
HD type	4K Ultra HD
Native aspect ratio	16:9
Display brightness	350 cd/m²
Panel type	IPS
Anti-glare screen	Yes
RGB colour space	sRGB
Colour gamut	100%

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 7
Processor generation	AMD Ryzen 5000 Series
Processor model	5800H
Processor cores	8
Processor boost frequency	4.4 GHz
Processor frequency	3.2 GHz
Processor cache	16 MB
Processor cache type	L3

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	3200 MHz
Memory layout (slots x size)	2 x 8 GB
Memory form factor	DIMM/SO-DIMM

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete GPU manufacturer	AMD
Discrete graphics card model	AMD Radeon RX 6600M
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	AMD
On-board graphics card	Yes
On-board graphics card family	AMD Radeon Graphics
On-board graphics card model	AMD Radeon Graphics

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	10 W
Speakers manufacturer	JBL
Built-in microphone	Yes
Audio chip	Realtek ALC274-CG
Audio system	Dolby Audio Premium

Camera

Specification	Value
Built-in camera	Yes

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.0

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB4 Gen 3x2 ports quantity	0
HDMI ports quantity	1
HDMI version	2.0
Combo headphone/mic port	Yes

Design

Specification	Value
Product colour	Grey, White
Colour name	Cloud grey and moon white

Performance

Specification	Value
Product type	All-in-One PC
Motherboard chipset	AMD SoC

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system architecture	64-bit

Power

Specification	Value
AC adapter power	300 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V

Weight & dimensions

Specification	Value
Width (with stand)	614 mm
Depth (with stand)	108 mm
Height (with stand)	460 mm
Weight (with stand)	11.8 kg

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12192 m

Certificates

Specification	Value
Compliance certificates	RoHS

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Technical details

Specification	Value
Box contents	Screen Projection
