Lenovo IdeaCentre 330-20IGM Intel® Pentium® Silver J5005

IdeaCentre 330-20IGM Intel® Pentium® Silver J5005

49.5 cm (19.5") 1440 x 900 pixels All-in-One PC 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.1

Model 330-20IGMPart no. F0D7005RGEEAN 193268177017

92 specifications

Display49.5 cm (19.5")
Resolution1440 x 900 pixels
ProcessorIntel® Pentium® Silver
Memory4 GB
Storage1 TB
SpeedWi-Fi 5 (802.11ac)

See all specifications

Overview

Display: 49.5 cm (19.5")
Resolution: 1440 x 900 pixels
Processor: Intel® Pentium® Silver
Memory: 4 GB
Storage: 1 TB
Speed: Wi-Fi 5 (802.11ac)

Brand: Lenovo
Category: All-in-One PCs/Workstations
Model: 330-20IGM
Part numbers: F0D7005RGE, F0D70005LD
EAN / UPC: 193268177017, 192158185880
Also known as: Lenovo IdeaCentre 330-20IGM Intel® Pentium® Silver J5005 49.5 cm (19.5") 1440 x 900 pixels All-in-One PC 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.1

Specifications

92 specifications in 18 groups

Display

Specification	Value
Display diagonal	49.5 cm (19.5")
Display resolution	1440 x 900 pixels
Touchscreen	No
HD type	WXGA+
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium® Silver
Processor model	J5005
Processor cores	4
Processor boost frequency	2.8 GHz
Processor frequency	1.5 GHz
Processor cache	4 MB
Processor cache type	Smart Cache
Conflict-Free processor	Yes

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	8 GB
Memory slots	1
Memory slots type	SO-DIMM
Memory clock speed	2400 MHz
Memory layout (slots x size)	1 x 4 GB
Memory form factor	DIMM/SO-DIMM

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	HDD
Number of storage drives installed	1
Number of storage drives supported	2
Total HDDs capacity	1 TB
Number of HDDs installed	1
HDD capacity	1 TB
HDD speed	5400 RPM
HDD size	2.5"
Optical drive type	DVD±RW
Card reader integrated	Yes

Graphics

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics 605

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	2 W
Built-in microphone	Yes

Camera

Specification	Value
Built-in camera	Yes
Camera HD type	HD

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Antenna type	1x1
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	4.0

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
HDMI ports quantity	1
Combo headphone/mic port	Yes
DC-in jack	Yes

Design

Specification	Value
Product colour	Black
On/off button	Yes

Performance

Specification	Value
Product type	All-in-One PC
Market positioning	Business
Motherboard chipset	Intel SoC

Software

Specification	Value
Operating system installed	Windows 10 Home
Operating system architecture	64-bit
Operating system language	German

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Smart Response Technology version	0.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes

Power

Specification	Value
AC adapter power	45 W

Weight & dimensions

Specification	Value
Width (with stand)	460.6 mm
Depth (with stand)	223.5 mm
Height (with stand)	394.9 mm
Weight (with stand)	3.9 kg

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	• ErP Lot 3 • RoHS compliant

Sustainability

Specification	Value
Sustainability certificates	ErP

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes
Keyboard language	German
Keyboard layout	QWERTY
Numeric keypad	Yes
