HP Pavilion 24-xa0550nd Intel® Core™ i7 i7-9700T
HP

Pavilion 24-xa0550nd Intel® Core™ i7 i7-9700T

60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1.25 TB HDD+SSD NVIDIA GeForce MX230 Windows 1

Model 24-xa0550ndPart no. 7JY24EA#ABH

144 specifications
  • Display60.5 cm (23.8")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i7
  • Memory8 GB
  • Storage1.25 TB
  • GraphicsNVIDIA GeForce MX230
See all specifications

Overview

Display
60.5 cm (23.8")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i7
Memory
8 GB
Storage
1.25 TB
Graphics
NVIDIA GeForce MX230
Brand
HP
Model
24-xa0550nd
Part number
7JY24EA#ABH
Also known as
HP Pavilion 24-xa0550nd Intel® Core™ i7 i7-9700T 60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1.25 TB HDD+SSD NVIDIA GeForce MX230 Windows 1

Specifications

144 specifications in 19 groups

Display

Display diagonal60.5 cm (23.8")
Display resolution1920 x 1080 pixels
TouchscreenNo
HD typeFull HD
LED backlightYes
Native aspect ratio16:9
Screen shapeFlat
Tilt angle range-5 - 25°

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation9th gen Intel® Core™ i7
Processor modeli7-9700T
Processor cores8
Processor threads8
Processor boost frequency4.3 GHz
Processor frequency2 GHz
Processor cache12 MB
Processor cache typeSmart Cache
Processor socketLGA 1151 (Socket H4)
System bus rate8 GT/s
Thermal Design Power (TDP)35 W
Configurable TDP-down frequency1.5 GHz
Configurable TDP-down25 W
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 2x8, 1x8+2x4
PCI Express slots version3.0
Processor codenameCoffee Lake
Processor lithography14 nm
Processor operating modes64-bit
Tjunction100 °C
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Memory bandwidth supported by processor (max)41.6 GB/s

Memory

Internal memory8 GB
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory slots2
Memory slots typeSO-DIMM
Memory clock speed2666 MHz
Memory layout (slots x size)1 x 8 GB
Memory form factorDIMM/SO-DIMM

Storage

Total storage capacity1.25 TB
Storage mediaHDD+SSD
Number of HDDs installed1
HDD capacity1 TB
HDD speed7200 RPM
HDD interfaceSATA
Number of SSDs installed1
SSD capacity256 GB
NVMeYes
SSD interfaceNVMe, PCI Express
SSD form factorM.2
Optical drive typeNo
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC

Graphics

Discrete graphics cardYes
Discrete graphics card modelNVIDIA GeForce MX230
Discrete graphics card memory2 GB
Discrete graphics memory typeGDDR5
On-board graphics cardYes
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1200 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x3E98
On-board graphics card OpenGL version4.5

Audio

Built-in speaker(s)Yes
Number of speakers2
RMS rated power4 W
Audio systemB&O PLAY

Camera

Built-in cameraYes
Camera HD typeHD
Infrared (IR) cameraYes

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Antenna type2x2
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
BluetoothYes
Bluetooth version4.2

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity2
Thunderbolt 3 ports quantity0
Thunderbolt ports quantity0
HDMI ports quantity2
HDMI version1.4
Headphone outputs0
Microphone inNo
Combo headphone/mic portYes

Design

Product colourWhite
Cable lock slotYes
Country of originChina

Performance

Product typeAll-in-One PC

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel TSX-NIYes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Turbo Boost Technology2.0
Processor ARK ID191048
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015A

Power

AC adapter power150 W

Pen

Pen includedNo

Weight & dimensions

Width (with stand)540.3 mm
Depth (with stand)160 mm
Height (with stand)442.4 mm
Weight (with stand)5.59 kg

Sustainability

Sustainability certificatesEPEAT Silver, ENERGY STAR

Packaging content

Mouse includedYes
Keyboard includedYes

Other features

3DNo
Autonomy modeNo
Detachable displayNo
