20 -c402na Intel® Celeron® J4005

49.5 cm (19.5") 1920 x 1080 pixels All-in-One PC 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Home White

Model 20-c402naPart no. 4FT46EAEAN 193015048690

145 specifications

Overview

Brand: HP
Category: All-in-One PCs/Workstations
Model: 20-c402na
Part number: 4FT46EA
EAN / UPC: 193015048690
Also known as: HP 20 -c402na Intel® Celeron® J4005 49.5 cm (19.5") 1920 x 1080 pixels All-in-One PC 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Home White

145 specifications in 20 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	J4005
Processor cores	2
Processor threads	2
Processor boost frequency	2.7 GHz
Processor frequency	2 GHz
Processor cache	4 MB
Processor cache type	L2
Processor socket	BGA 1090
Thermal Design Power (TDP)	10 W
Maximum number of PCI Express lanes	6
PCI Express configurations	1x2, 1x2+2x1, 1x4, 2x1, 4x1
PCI Express slots version	2.0
Processor codename	Gemini Lake
Processor lithography	14 nm
Processor operating modes	64-bit
Tjunction	105 °C
Conflict-Free processor	Yes
Maximum internal memory supported by processor	8 GB
Memory types supported by processor	DDR4-SDRAM, LPDDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
Memory channels supported by processor	Dual
ECC supported by processor	No

Specification	Value
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics 600
Maximum on-board graphics card memory	8 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	250 MHz
On-board graphics card burst frequency	700 MHz
On-board graphics card dynamic frequency (max)	700 MHz
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x3185
Number of execution units	12

Specification	Value
Built-in camera	Yes

Specification	Value
Wi-Fi	Yes
WLAN controller manufacturer	Realtek
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN controller model	Realtek RTL8821CE
Antenna type	1x1
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	4.2

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
Thunderbolt ports quantity	0
HDMI ports quantity	1
HDMI version	1.4
VGA (D-Sub) ports quantity	0
Headphone outputs	0
Microphone in	No
Combo headphone/mic port	Yes
DC-in jack	Yes

Specification	Value
Product colour	White
Country of origin	China

Specification	Value
Product type	All-in-One PC

Specification	Value
Operating system installed	Windows 10 Home
Operating system architecture	64-bit
Trial software	Netflix, Microsoft Office 365, McAfee LiveSafe
Bundled software	Dropbox

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Smart Response Technology version	0.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	128992
Processor package size	25 x 24 mm
Thermal Monitoring Technologies	Yes
UART	Yes

Specification	Value
AC adapter power	65 W

Specification	Value
Pen included	No
