Dell XPS 7760 Intel® Core™ i7 i7-6700

68.6 cm (27") 3840 x 2160 pixels Touchscreen All-in-One PC 32 GB DDR4-SDRAM 2 TB HDD+SSD AMD Radeon R9 M485X Windows 10 Ho

Model 7760Part no. D-7760-N2-712KEAN 5397063969104

170 specifications

Display68.6 cm (27")
Resolution3840 x 2160 pixels
ProcessorIntel® Core™ i7
Memory32 GB
Storage2 TB
GraphicsAMD Radeon R9 M485X

See all specifications

Overview

Display: 68.6 cm (27")
Resolution: 3840 x 2160 pixels
Processor: Intel® Core™ i7
Memory: 32 GB
Storage: 2 TB
Graphics: AMD Radeon R9 M485X

Brand: Dell
Category: All-in-One PCs/Workstations
Model: 7760
Part numbers: D-7760-N2-712K, CAX2710W10HS400, DDCWDUCKB403S, FDCWDUCKB400S, FDCWDUCKB405S, CAX2710W10HS403 +34 more
EAN / UPC: 5397063969104, 5397184230268, 5397184230237, 5397184230282 +19 more
Also known as: DELL XPS 7760 Intel® Core™ i7 i7-6700 68.6 cm (27") 3840 x 2160 pixels Touchscreen All-in-One PC 32 GB DDR4-SDRAM 2 TB HDD+SSD AMD Radeon R9 M485X Windows 10 Ho

Specifications

170 specifications in 18 groups

Display

Specification	Value
Display diagonal	68.6 cm (27")
Display resolution	3840 x 2160 pixels
Touchscreen	Yes
HD type	4K Ultra HD
LED backlight	Yes
Native aspect ratio	16:9
Pixel pitch	0.1554 x 0.1554 mm
Screen shape	Flat

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	6th gen Intel® Core™ i7
Processor model	i7-6700
Processor cores	4
Processor threads	8
Processor boost frequency	4 GHz
Processor frequency	3.4 GHz
Processor cache	8 MB
Processor cache type	Smart Cache
Processor socket	LGA 1151 (Socket H4)
System bus rate	8 GT/s
Thermal Design Power (TDP)	65 W
Bus type	DMI3
Maximum number of PCI Express lanes	16
PCI Express configurations	2x8, 1x8+2x4, 1x16
PCI Express slots version	3.0
Processor code	SR2BT
Processor codename	Skylake
Processor lithography	14 nm
Processor operating modes	64-bit
Processor series	Intel Core i7-6700 Desktop series
Stepping	R0
Tcase	71 °C
Conflict-Free processor	Yes
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor	1333,1600,1866,2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Memory channels supported by processor	Dual
ECC supported by processor	No
Memory voltage supported by processor	1.35 V

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory slots	4
Memory slots type	SO-DIMM
Memory form factor	DIMM/SO-DIMM

Storage

Specification	Value
Total storage capacity	2 TB
Storage media	HDD+SSD
Number of storage drives installed	2
Number of HDDs installed	1
HDD capacity	2 TB
HDD interface	SATA III
Number of SSDs installed	1
SSD capacity	32 GB
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SDHC, SDXC

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	AMD Radeon R9 M485X
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card	Yes
On-board graphics card model	Intel® HD Graphics 530
Maximum on-board graphics card memory	1.74 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
On-board graphics card DirectX version	12.0
On-board graphics card ID	1912
On-board graphics card OpenGL version	4.4

Audio

Specification	Value
Built-in speaker(s)	Yes
RMS rated power	10 W
Speakers manufacturer	Waves
Built-in microphone	Yes
Audio system	Waves MaxxAudio Pro

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	0.92 MP
Camera resolution	1280 x 720 pixels

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	4.0

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Thunderbolt ports quantity	0
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone outputs	0
Microphone in	No
Audio output	Yes
Combo headphone/mic port	Yes
USB Sleep-and-Charge	Yes
USB Sleep-and-Charge ports	1

Design

Specification	Value
Product colour	Black, Grey
On/off button	Yes

Performance

Specification	Value
Product type	All-in-One PC
Motherboard chipset	Intel® H170

Software

Specification	Value
Operating system installed	Windows 10 Home
Operating system architecture	64-bit

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	14 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel Stable Image Platform Program (SIPP) version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes
Processor ARK ID	88196
Processor package size	37.5 x 37.5 mm
Scalability	1S
Supported instruction sets	SSE4.1, AVX 2.0, SSE4.2
Thermal Monitoring Technologies	Yes
Thermal solution specification	PCG 2015C
Thunderbolt™ 3 Technology	Yes

Power

Specification	Value
AC adapter power	360 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V

Weight & dimensions

Specification	Value
Width (with stand)	624.8 mm
Depth (with stand)	260 mm
Height (with stand)	435.1 mm
Weight (with stand)	17.3 kg
Depth (without stand)	80.2 mm

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	-15.2 - 3048 m

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes
Warranty card	Yes
AC adapter included	Yes
Drivers included	Yes
Power cord included	Yes
Quick start guide	Yes
Manual	Yes

Other features

Specification	Value
Autonomy mode	No
Detachable display	No
