ASUS M3402WFAK-WPC005W AMD Ryzen™ 5 7520U

M3402WFAK-WPC005W AMD Ryzen™ 5 7520U

60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 8 GB LPDDR5-SDRAM 512 GB SSD Windows 11 Home Wi-Fi 6E (802.11ax) Whit

Model M3402WFAK-WPC005WPart no. 90PT03L1-M00KJ0EAN 197105690158

95 specifications

Display60.5 cm (23.8")
Resolution1920 x 1080 pixels
ProcessorAMD Ryzen™ 5
Memory8 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 60.5 cm (23.8")
Resolution: 1920 x 1080 pixels
Processor: AMD Ryzen™ 5
Memory: 8 GB
Storage: 512 GB
Graphics: Not available

Brand: ASUS
Category: All-in-One PCs/Workstations
Model: M3402WFAK-WPC005W
Part number: 90PT03L1-M00KJ0
EAN / UPC: 197105690158, 4711387690154
Also known as: ASUS M3402WFAK-WPC005W AMD Ryzen™ 5 7520U 60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 8 GB LPDDR5-SDRAM 512 GB SSD Windows 11 Home Wi-Fi 6E (802.11ax) Whit

Specifications

95 specifications in 17 groups

Display

Specification	Value
Display diagonal	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels
Touchscreen	No
HD type	Full HD
Native aspect ratio	16:9
Display brightness	250 cd/m²
Panel type	LCD
Anti-glare screen	Yes
RGB colour space	sRGB
Colour gamut	100%

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 5
Processor model	7520U
Processor cores	4
Processor boost frequency	4.3 GHz
Processor frequency	2.8 GHz
Processor cache	4 MB
Processor cache type	L3

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	LPDDR5-SDRAM
Maximum internal memory	8 GB
Memory form factor	On-board

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 3.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MMC, SD

Graphics

Specification	Value
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card model	AMD Radeon 610M

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	6 W
Built-in microphone	Yes
Audio system	Sonic Master

Camera

Specification	Value
Built-in camera	Yes
Camera HD type	HD
Camera resolution	1280 x 720 pixels
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	1x1
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB4 Gen 3x2 ports quantity	0
HDMI ports quantity	2
HDMI version	1.4
Combo headphone/mic port	Yes
DC-in jack	Yes
Number of rear USB ports	5
Number of side USB ports	1
Number of side audio ports	1

Design

Specification	Value
Product colour	White
Colour name	White
Cable lock slot	Yes
Cable lock slot type	Kensington
Introduction year	2023

Performance

Specification	Value
Product type	All-in-One PC
Trusted Platform Module (TPM)	Yes
BIOS password	Yes
HDD user password	Yes

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Trial software	1-month trial for new Microsoft 365 customers

Power

Specification	Value
AC adapter power	90 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V

Weight & dimensions

Specification	Value
Width (with stand)	529 mm
Depth (with stand)	165 mm
Height (with stand)	423 mm
Weight (with stand)	5.4 kg

Certificates

Specification	Value
Compliance certificates	REACH

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Silver

Packaging content

Specification	Value
Mouse connectivity	Wired
Mouse included	Yes
Keyboard connectivity	Wired
Keyboard included	Yes
