ASUS ET1611PUT-W0177 All-in-One PC/workstation Intel Atom® D425

39.6 cm (15.6") 1366 x 768 pixels Touchscreen 2 GB DDR3-SDRAM 64 GB SSD Windows 7 Home Premium W

Model ET1611PUT-W0177

120 specifications

Display39.6 cm (15.6")
Resolution1366 x 768 pixels
ProcessorIntel Atom®
Memory2 GB
Storage64 GB
GraphicsNot available

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1366 x 768 pixels
Processor: Intel Atom®
Memory: 2 GB
Storage: 64 GB
Graphics: Not available

Brand: ASUS
Category: All-in-One PCs/Workstations
Model: ET1611PUT-W0177
Part number: ET1611PUT-W0177
Also known as: ASUS ET1611PUT-W0177 All-in-One PC/workstation Intel Atom® D425 39.6 cm (15.6") 1366 x 768 pixels Touchscreen 2 GB DDR3-SDRAM 64 GB SSD Windows 7 Home Premium W

Specifications

120 specifications in 16 groups

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1366 x 768 pixels
Touchscreen	Yes
HD type	Not supported
Full HD	No
LED backlight	Yes
Touch technology	Single-touch
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D425
Processor cores	1
Processor threads	2
Processor frequency	1.8 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor socket	BGA 559
64-bit computing	Yes
Thermal Design Power (TDP)	10 W
Bus type	DMI
FSB Parity	No
Number of Processing Die Transistors	123 M
Processing Die size	66 mm²
Processor code	SLBXD
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Atom D400 Series
Stepping	A0
Tjunction	100 °C
Conflict-Free processor	No
Maximum internal memory supported by processor	4 GB
Memory types supported by processor	DDR3 800 (SODIMM only); DDR2 667/800
Memory bandwidth supported by processor (max)	6.4 GB/s
Memory channels supported by processor	Single
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	2 GB
Memory slots	1
Memory slots type	SO-DIMM
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 1 GB

Storage

Specification	Value
Total storage capacity	64 GB
Storage media	SSD
Number of storage drives installed	1
Number of SSDs installed	1
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD

Graphics

Specification	Value
Discrete graphics card model	Not available
On-board graphics card	Yes

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	0.3 MP

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	0
VGA (D-Sub) ports quantity	1
Headphone outputs	1
Microphone in	Yes
DC-in jack	Yes

Design

Specification	Value
Product colour	White
Cable lock slot	Yes
Wall mountable	Yes

Performance

Specification	Value
Motherboard chipset	Intel® NM10 Express
Placement supported	Horizontal

Software

Specification	Value
Operating system installed	Windows 7 Home Premium

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	49489
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No

Power

Specification	Value
AC adapter power	40 W

Weight & dimensions

Specification	Value
Width (with stand)	407.4 mm
Depth (with stand)	42.5 mm
Height (with stand)	336.6 mm
Weight (with stand)	3.1 kg

Packaging content

Specification	Value
Mouse included	No
Keyboard included	No
AC adapter included	Yes
Cables included	AC
Quick start guide	Yes

Other features

Specification	Value
Graphics card family	Intel
COM ports quantity	1
Ethernet interface type	Gigabit Ethernet
Intel segment tagging	Enterprise, Small Business
