ET ET1611PUT-B005F All-in-One PC/workstation Intel Atom® D425

39.6 cm (15.6") 1366 x 768 pixels Touchscreen 2 GB DDR3-SDRAM 320 GB Intel® GMA 3150 Windows

Model ET1611PUT-B005FEAN 4719543390399

133 specifications

Overview

Brand: ASUS
Category: All-in-One PCs/Workstations
Model: ET1611PUT-B005F
Part number: ET1611PUT-B005F
EAN / UPC: 4719543390399
Also known as: ASUS ET ET1611PUT-B005F All-in-One PC/workstation Intel Atom® D425 39.6 cm (15.6") 1366 x 768 pixels Touchscreen 2 GB DDR3-SDRAM 320 GB Intel® GMA 3150 Windows

133 specifications in 16 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D425
Processor cores	1
Processor threads	2
Processor frequency	1.8 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor socket	BGA 559
Thermal Design Power (TDP)	10 W
Bus type	DMI
FSB Parity	No
Number of Processing Die Transistors	123 M
Processing Die size	66 mm²
Processor code	SLBXD
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Atom D400 Series
Stepping	A0
Tjunction	100 °C
Conflict-Free processor	No
Maximum internal memory supported by processor	4 GB
Memory types supported by processor	DDR3 800 (SODIMM only); DDR2 667/800
Memory bandwidth supported by processor (max)	6.4 GB/s
Memory channels supported by processor	Single
ECC supported by processor	No

Specification	Value
Discrete graphics card model	Intel® GMA 3150
On-board graphics card	Yes

Specification	Value
Built-in microphone	Yes

Specification	Value
Built-in camera	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	0
VGA (D-Sub) ports quantity	1
DVI port	No
Headphone outputs	1
Microphone in	Yes
DC-in jack	Yes
Firewire (IEEE 1394) ports	0
PS/2 ports quantity	0
Serial ports quantity	0

Specification	Value
Operating system installed	Windows 7 Professional
Bundled software	Windows Live; Eee Manager; Easy Update; Adobe Reader; Asus Update; Office Starter 2010

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	49489
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No

Specification	Value
Power consumption (standby)	0.311 W
Power consumption (typical)	29.25 W

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Specification	Value
Graphics card family	Intel
COM ports quantity	1
Cabling technology	10/100/1000Base-T(X)
Chassis type	All-in-One
Display	LED
Display included	Yes
Floppy drive installed	No
Maximum graphics card memory	128 MB
Megapixel (approx.)	0.3 MP
Networking features	Gigabit Ethernet
Number of processors installed	1
Parallel ports quantity	0
Power supply	40 W
Rack mounting	Yes
Speakers	2
TV tuner integrated	No
Intel segment tagging	Enterprise, Small Business
