ASUS ET ET1611PUT-B004E Intel Atom® D425

39.6 cm (15.6") 1366 x 768 pixels Touchscreen All-in-One PC 2 GB DDR3-SDRAM 250 GB HDD Windows 7 Home Premium Black

Model ET1611PUT-B004EPart no. 90PE3XA21121E10A5C0QEAN 4719543379356

141 specifications

Display39.6 cm (15.6")
Resolution1366 x 768 pixels
ProcessorIntel Atom®
Memory2 GB
Storage250 GB
GraphicsNot available

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1366 x 768 pixels
Processor: Intel Atom®
Memory: 2 GB
Storage: 250 GB
Graphics: Not available

Brand: ASUS
Category: All-in-One PCs/Workstations
Model: ET1611PUT-B004E
Part number: 90PE3XA21121E10A5C0Q
EAN / UPC: 4719543379356
Also known as: ASUS ET ET1611PUT-B004E Intel Atom® D425 39.6 cm (15.6") 1366 x 768 pixels Touchscreen All-in-One PC 2 GB DDR3-SDRAM 250 GB HDD Windows 7 Home Premium Black

Specifications

141 specifications in 16 groups

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1366 x 768 pixels
Touchscreen	Yes
HD type	Not supported
Full HD	No
Touch technology	Single-touch
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D425
Processor cores	1
Processor threads	2
Processor frequency	1.8 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor socket	BGA 559
Thermal Design Power (TDP)	10 W
Bus type	DMI
FSB Parity	No
Number of Processing Die Transistors	123 M
Processing Die size	66 mm²
Processor code	SLBXD
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Atom D400 Series
Stepping	A0
Tjunction	100 °C
Conflict-Free processor	No
Maximum internal memory supported by processor	4 GB
Memory types supported by processor	DDR3 800 (SODIMM only); DDR2 667/800
Memory bandwidth supported by processor (max)	6.4 GB/s
Memory channels supported by processor	Single
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	2 GB
Memory slots	1x SO-DIMM
Memory clock speed	800 MHz
Memory layout (slots x size)	1 x 2 GB

Storage

Specification	Value
Total storage capacity	250 GB
Storage media	HDD
Number of HDDs installed	1
HDD capacity	250 GB
HDD speed	5400 RPM
HDD size	2.5"
HDD interface	SATA II
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SDHC

Graphics

Specification	Value
Discrete graphics card model	Not available
On-board graphics card	Yes

Audio

Specification	Value
Built-in microphone	Yes
Audio system	HD

Camera

Specification	Value
Built-in camera	Yes

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	0
VGA (D-Sub) ports quantity	1
DVI port	No
Headphone outputs	1
Microphone in	Yes
Combo headphone/mic port	No
Firewire (IEEE 1394) ports	0
Docking connector	No
PS/2 ports quantity	0
Serial ports quantity	0
S/PDIF out port	No

Design

Specification	Value
Product colour	Black

Performance

Specification	Value
Product type	All-in-One PC

Software

Specification	Value
Operating system installed	Windows 7 Home Premium
Operating system architecture	64-bit

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	49489
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No

Weight & dimensions

Specification	Value
Width (with stand)	407.4 mm
Depth (with stand)	42.5 mm
Height (with stand)	336.6 mm
Weight (with stand)	3.1 kg

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Other features

Specification	Value
3D	No
Graphics card family	Intel
COM ports quantity	1
Cabling technology	10/100/1000Base-T(X)
Chassis type	All-in-One
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Display	LED
Display included	Yes
Floppy drive installed	No
Mac compatibility	No
Maximum number of SMP processors	1
Megapixel (approx.)	0.3 MP
Networking features	Gigabit Ethernet
Number of processors installed	1
Parallel ports quantity	0
Platform	PC
Power supply	40 W
Power supply type	AC/DC
SmartCard slot	No
Speakers	monitor built-in
Wake-on-LAN ready	Yes
Intel segment tagging	Enterprise, Small Business
