Eee TOP ET2010PNT-B035E
Model Eee TOP ET2010PNT-B035EPart no. 90PE3GA21316E105MC0CEAN 4719543308561
111 specifications
- Display50.8 cm (20")
- ProcessorIntel Atom®
- Memory2 GB
- Storage500 GB
- OSWindows 7 Home Premium
- ColourBlack
Overview
- Display
- 50.8 cm (20")
- Processor
- Intel Atom®
- Memory
- 2 GB
- Storage
- 500 GB
- OS
- Windows 7 Home Premium
- Colour
- Black
- Brand
- ASUS
- Category
- All-in-One PCs/Workstations
- Model
- Eee TOP ET2010PNT-B035E
- Part number
- 90PE3GA21316E105MC0C
- EAN / UPC
- 4719543308561
- Also known as
- ASUS Eee PC Eee TOP ET2010PNT-B035E Intel Atom® D510 50.8 cm (20") 2 GB DDR2-SDRAM 500 GB Windows 7 Home Premium Black
Specifications
111 specifications in 14 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 50.8 cm (20") |
| Display brightness | 250 cd/m² |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Atom® |
| Processor model | D510 |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor frequency | 1.66 GHz |
| Processor cache | 1 MB |
| Processor cache type | L2 |
| Processor socket | BGA 559 |
| Thermal Design Power (TDP) | 13 W |
| Bus type | DMI |
| FSB Parity | No |
| Number of Processing Die Transistors | 176 M |
| Processing Die size | 87 mm² |
| Processor code | SLBLA |
| Processor codename | Pineview |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Atom D500 Series |
| Stepping | B0 |
| Tjunction | 100 °C |
| Conflict-Free processor | No |
| Maximum internal memory supported by processor | 4 GB |
| Memory types supported by processor | DDR2 667/800 |
| Memory bandwidth supported by processor (max) | 6.4 GB/s |
| Memory channels supported by processor | Single |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR2-SDRAM |
| Maximum internal memory | 4 GB |
| Memory clock speed | 800 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| HDD speed | 7200 RPM |
| HDD interface | SATA II |
| Optical drive type | DVD Super Multi |
| Card reader integrated | Yes |
| Compatible memory cards | MMC, SD, SDHC |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 6 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Firewire (IEEE 1394) ports | 0 |
| PS/2 ports quantity | 0 |
| Serial ports quantity | 0 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Home Premium |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | No |
| Execute Disable Bit | Yes |
| Idle States | No |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® Turbo Boost Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Physical Address Extension (PAE) | 32 bit |
| Processor ARK ID | 43098 |
| Processor package size | 22 x 22 mm |
| Supported instruction sets | SSE2, SSE3, SSSE3 |
| Thermal Monitoring Technologies | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 496.8 mm |
| Depth (with stand) | 20.3 mm |
| Height (with stand) | 373.3 mm |
| Weight (with stand) | 6 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | No |
Other features
| Specification | Value |
|---|---|
| Chassis type | All-in-One |
| Display included | Yes |
| Floppy drive installed | No |
| Hot keys | 10 |
| Keyboard number of keys | 86 |
| Mac compatibility | No |
| Maximum graphics card memory | 512 MB |
| Number of processors installed | 1 |
| Parallel ports quantity | 0 |
| Power supply | 90 W |
| Speakers | 2 |
| TV tuner integrated | No |
| Wireless technology | 802.11n |
| Intel segment tagging | Enterprise, Small Business |
