ASUS ExpertCenter E1 AiO E1600WKAT-BMR048M Intel® Celeron® N N4500

ExpertCenter E1 AiO E1600WKAT-BMR048M Intel® Celeron® N N4500

39.6 cm (15.6") 1920 x 1080 pixels Touchscreen All-in-One tablet PC 4 GB DDR4-SDRAM 512 GB SS

Model E1600WKAT-BMR048MPart no. 90PT0391-M00XP0EAN 197105653948

94 specifications

Display39.6 cm (15.6")
Resolution1920 x 1080 pixels
ProcessorIntel® Celeron® N
Memory4 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1920 x 1080 pixels
Processor: Intel® Celeron® N
Memory: 4 GB
Storage: 512 GB
Graphics: Not available

Brand: ASUS
Category: All-in-One PCs/Workstations
Model: E1600WKAT-BMR048M
Part number: 90PT0391-M00XP0
EAN / UPC: 197105653948, 4711387653944
Also known as: ASUS ExpertCenter E1 AiO E1600WKAT-BMR048M Intel® Celeron® N N4500 39.6 cm (15.6") 1920 x 1080 pixels Touchscreen All-in-One tablet PC 4 GB DDR4-SDRAM 512 GB SS

Specifications

94 specifications in 18 groups

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1920 x 1080 pixels
Touchscreen	Yes
HD type	Full HD
Native aspect ratio	16:9
Display brightness	250 cd/m²
Display surface	Gloss
Panel type	TN
Anti-glare screen	Yes
Contrast ratio (typical)	500:1
Maximum refresh rate	60 Hz
RGB colour space	NTSC
Colour gamut	45%

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron® N
Processor model	N4500
Processor cores	2
Processor boost frequency	2.8 GHz
Processor frequency	1.1 GHz
Processor cache	4 MB
Processor cache type	Smart Cache

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	8 GB
Memory slots type	SO-DIMM

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 3.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MMC, SD

Graphics

Specification	Value
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics

Audio

Specification	Value
Built-in speaker(s)	Yes

Camera

Specification	Value
Built-in camera	Yes
Camera HD type	HD
Camera resolution	1280 x 720 pixels

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.0

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB4 Gen 3x2 ports quantity	0
HDMI ports quantity	1
HDMI version	1.4
Combo headphone/mic port	Yes
DC-in jack	Yes

Design

Specification	Value
Product colour	Black
Colour name	Black
Cable lock slot	Yes
Cable lock slot type	Kensington

Performance

Specification	Value
Product type	All-in-One tablet PC
Market positioning	Business
Trusted Platform Module (TPM)	Yes
BIOS password	Yes
HDD user password	Yes

Software

Specification	Value
Operating system installed	No

Power

Specification	Value
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V

Weight & dimensions

Specification	Value
Width (with stand)	366 mm
Depth (with stand)	247 mm
Height (with stand)	150 mm
Weight (with stand)	2.24 kg
Depth (without stand)	37 mm

Certificates

Specification	Value
Compliance certificates	REACH

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Silver
Sustainability compliance	Yes

Packaging content

Specification	Value
Mouse connectivity	Wired
Mouse included	Yes
Mouse included on selected markets	Yes
Keyboard connectivity	Wired
Keyboard included on selected markets	Yes
Keyboard language	US International
Keyboard layout	QWERTY

Other features

Specification	Value
COM ports quantity	2
