APC SURTD5000RMXLI uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA

APC SURTD5000RMXLI uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA

3500 W 10 AC outlet(s)

Model SURTD5000RMXLIPart no. SURTD5000RMXLI+3JAHREGARANTIE

60 specifications
  • Noise55 dB
  • TypeRackmount
  • Weight54.5 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesC13 coupler, C19 coupler
See all specifications

Overview

Noise
55 dB
Type
Rackmount
Weight
54.5 kg
Colour
Black
UPS topology
Double-conversion (Online)
AC outlet types
C13 coupler, C19 coupler
Brand
APC
Model
SURTD5000RMXLI
Part number
SURTD5000RMXLI+3JAHREGARANTIE
Also known as
APC SURTD5000RMXLI uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 3500 W 10 AC outlet(s)

Specifications

60 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity5 kVA
Output power3500 W
WaveformSine
Input operation voltage (min)100 V
Input operation voltage (max)280 V
Input frequency45/65 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating555 J
Efficiency92%
Crest factor3:1
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)3%
Noise level55 dB
Power protection featuresOverload
Audible alarm(s)Yes
Auto-restartYes

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
Power plugTerminal
AC outlets quantity10 AC outlet(s)
Number of output IEC jumpers4
Serial ports quantity1
Ethernet LAN (RJ-45) ports1

Battery

Battery technologySealed Lead Acid (VRLA)
Number of batteries supported2
Typical backup time at full load6.3 min
Typical backup time at half load18.2 min
Battery recharge time2.50 h
Hot-swap batteryYes
Automatic battery testYes
Cold startYes

Design

Form factorRackmount
Product colourBlack
Rack capacity3U
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Certificates

Compliance certificatesRoHS
CertificationC-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, EN 61000-3-2, GOST, OSHPD, UL 1778, VDE

Weight & dimensions

Width432 mm
Depth660 mm
Height130 mm
Weight54.5 kg

Packaging data

Package width603 mm
Package depth980 mm
Package height347 mm
Package weight63.6 kg

Other features

Number of phases1
Output connections8 x IEC 320 C13 & 2 x IEC 320 C19
Input connection typeHardWire 3-wire
Management platformSNMP
Nominal input voltage230 V
Nominal output voltage230 V
Communication options, slotSmartSlot
