APC SURT20KRMXLI + WBEXTWAR3YR-SP-08

APC SURT20KRMXLI + WBEXTWAR3YR-SP-08

Model SURT20KRMXLI + WBEXTWAR3YR-SP-08

47 specifications
  • Noise59 dB
  • TypeRackmount
  • Weight247.7 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesC19 coupler
See all specifications

Overview

Noise
59 dB
Type
Rackmount
Weight
247.7 kg
Colour
Black
UPS topology
Double-conversion (Online)
AC outlet types
C19 coupler
Brand
APC
Model
SURT20KRMXLI + WBEXTWAR3YR-SP-08
Part number
SURT20KRMXLI + WBEXTWAR3YR-SP-08
Also known as
APC SURT20KRMXLI + WBEXTWAR3YR-SP-08 uninterruptible power supply (UPS) Double-conversion (Online) 20 kVA 16000 W 12 AC outlet(s)

Specifications

47 specifications in 8 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity20 kVA
Output power16000 W
WaveformSine
Input operation voltage (min)230 V
Input operation voltage (max)230 V
Input frequency40 - 70 Hz
Output operation voltage (min)230 V
Output operation voltage (max)230 V
Output frequency regulation47/63 Hz
Output voltage regulation5%
Maximum current105 A
Emergency Power Off (EPO)Yes
Noise level59 dB
Power protection featuresOverload
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesC19 coupler
AC outlets quantity12 AC outlet(s)
Number of output IEC jumpers2
RS-232 ports1
Serial ports quantity1
Ethernet LAN (RJ-45) ports1

Battery

Battery technologySealed Lead Acid (VRLA)
Typical backup time at full load4.9 min
Typical backup time at half load15.3 min
Battery recharge time2.5 h

Design

Form factorRackmount
Product colourBlack
Rack capacity12U
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Certificates

Compliance certificatesRoHS
CertificationBSMI, EN/IEC 62040-2, EN/IEC 62040-1-1, VDE

Weight & dimensions

Width432 mm
Depth773 mm
Height533 mm
Weight247.7 kg

Packaging data

Package width610 mm
Package depth1003 mm
Package height990 mm
Package weight314.1 kg
