LG OLED77C9PLA.AVS TV

OLED77C9PLA.AVS TV

195.6 cm (77") 4K Ultra HD Smart TV Wi-Fi Black, Silver

Model OLED77C9PLA.AVSEAN 8806098384327

106 specifications Checked today

Display195.6 cm (77")
Resolution3840 x 2160 pixels
Energy classA
OSWebOS
ColourBlack, Silver
Tuner typeAnalog & digital

See all specifications

Overview

Display: 195.6 cm (77")
Resolution: 3840 x 2160 pixels
Energy class: A
OS: WebOS
Colour: Black, Silver
Tuner type: Analog & digital

Brand: LG
Category: TV
Model: OLED77C9PLA.AVS
Part number: OLED77C9PLA.AVS
EAN / UPC: 8806098384327
Also known as: LG OLED77C9PLA.AVS TV 195.6 cm (77") 4K Ultra HD Smart TV Wi-Fi Black, Silver

Specifications

106 specifications in 14 groups

Display

Specification	Value
Display diagonal	195.6 cm (77")
HD type	4K Ultra HD
Display resolution	3840 x 2160 pixels
Display technology	OLED
Screen shape	Flat
Native aspect ratio	16:9
Response time	1 ms
Display diagonal (metric)	195 cm
Peak luminance ratio	65%

TV tuner

Specification	Value
Tuner type	Analog & digital
Digital signal format system	DVB-C, DVB-S2, DVB-T2

Smart TV

Specification	Value
Smart TV	Yes
Internet TV	Yes
Operating system installed	WebOS
Operating system version	4.5
Timeshift	Yes
Apple AirPlay 2 support	Yes
Hybrid Broadcast Broadband TV (HbbTV)	Yes
Smart modes	Cinema, Energy saving, Game, Sports, Standard, Vivid
Video apps	Amazon Prime Video, Catch-up TV, Mediaset Play, Netflix, YouTube

Audio

Specification	Value
Number of speakers	2
Audio output channels	2.2 channels
RMS rated power	40 W
Built-in subwoofer	Yes
Audio decoders	DTS, Dolby Atmos, Dolby Digital

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth	Yes
Bluetooth version	5.0
Ethernet LAN	Yes
Miracast	Yes
Web browser	Yes

Design

Specification	Value
Product colour	Black, Silver
VESA mounting	Yes
Panel mounting interface	400 x 200 mm
Mercury content	0 mg

Performance

Specification	Value
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Teletext function	Yes
Teletext	2000 pages
Video formats supported	HEVC, VP9
Dolby Vision	Yes
Backlight dimming technology	Local Dimming
Noise reduction	Yes
USB recording	Yes

Ports & interfaces

Specification	Value
HDMI ports quantity	4
HDMI version	2.1
PC in (D-Sub)	No
DVI port	No
DVI-D ports quantity	0
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	3
Component video (YPbPr/YCbCr) in	0
Composite video in	0
Digital audio optical out	1
Headphone outputs	1
RF ports quantity	2
Common interface (CI)	Yes
Common interface Plus (CI+)	Yes
Common interface Plus (CI+) version	1.4
S-Video inputs quantity	0

Management features

Specification	Value
Electronic Programme Guide (EPG)	Yes
Number of OSD languages	36
Picture-in-Picture	Yes
Works with Amazon Alexa	Yes
Works with the Google Assistant	Yes

Power

Specification	Value
Power consumption (typical)	179 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy saving mode	Yes

Weight & dimensions

Specification	Value
Width (with stand)	1722 mm
Depth (with stand)	253 mm
Height (with stand)	1047 mm
Weight (with stand)	36.5 kg
Width (without stand)	1722 mm
Depth (without stand)	56 mm
Height (without stand)	991 mm
Weight (without stand)	29.9 kg

Packaging data

Specification	Value
Package width	1895 mm
Package depth	285 mm
Package height	1130 mm
Package weight	49.5 kg
Package type	Box

Packaging content

Specification	Value
Desktop stand	Yes
Cables included	AC
Remote control included	Yes
Remote control type	MR19

Other features

Specification	Value
3D	No
Batteries included	Yes
Battery type	AA
Number of batteries supported	2
Built-in speaker(s)	Yes
Compatible with universal remote control	Yes
Mediaset Premium Ready	No
Premium Smart CAM Ready	Yes
Intelligent Voice Recognition	Yes
Annual energy consumption	248 kWh
Digital Living Network Alliance (DLNA) certified	Yes
Energy efficiency class (legacy scale)	A
App store	LG Content Store
Google applications	Google Home
MagicLink	Yes
Wireless speaker ready	Yes
Advanced Colour Enhancer	Yes
Virtual Reality (VR) ready	Yes
