LG OLED77C8LLA TV

OLED77C8LLA TV

195.6 cm (77") 4K Ultra HD Smart TV Wi-Fi Black, Grey

Model OLED77C8LLAEAN 8806098204670

108 specifications Checked today

Display195.6 cm (77")
Resolution3840 x 2160 pixels
Energy classA
OSWebOS
ColourBlack, Grey
Tuner typeAnalog & digital

See all specifications

Overview

Display: 195.6 cm (77")
Resolution: 3840 x 2160 pixels
Energy class: A
OS: WebOS
Colour: Black, Grey
Tuner type: Analog & digital

Brand: LG
Category: TV
Model: OLED77C8LLA
Part number: OLED77C8LLA
EAN / UPC: 8806098204670, 8806098204649, 8806098204656, 8806098204687 +1 more
Also known as: LG OLED77C8LLA TV 195.6 cm (77") 4K Ultra HD Smart TV Wi-Fi Black, Grey

Specifications

108 specifications in 15 groups

Display

Specification	Value
Display diagonal	195.6 cm (77")
HD type	4K Ultra HD
Display resolution	3840 x 2160 pixels
Display technology	OLED
Screen shape	Flat
Native aspect ratio	16:9
Screen format adjustments	4:3, 16:9, Auto
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160
Supported video modes	1080p, 2160p
Colour depth	10 bit
Display diagonal (metric)	195 cm
Peak luminance ratio	65%

TV tuner

Specification	Value
Tuner type	Analog & digital
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-C2, DVB-S2, DVB-T, DVB-T2
Auto channel search	Yes
Supported TV bands	S Band, UHF, VHF

Smart TV

Specification	Value
Smart TV	Yes
Internet TV	Yes
Operating system installed	WebOS
Operating system version	4.0
Timeshift	Yes
Hybrid Broadcast Broadband TV (HbbTV)	Yes
Video apps	Amazon Prime Video, Netflix

Audio

Specification	Value
Number of speakers	2
RMS rated power	40 W
Built-in subwoofer	Yes
Subwoofer RMS power	20 W
Audio decoders	DTS, Dolby Atmos
Equalizer	Yes

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth	Yes
Bluetooth version	4.2
Ethernet LAN	Yes
Wi-Fi Direct	Yes
Miracast	Yes
Web browser	Yes

Design

Specification	Value
Product colour	Black, Grey
VESA mounting	Yes
Panel mounting interface	400 x 200 mm
On/off switch	Yes

Performance

Specification	Value
High Dynamic Range (HDR) supported	Yes
Game mode	Yes
Video formats supported	HEVC
Backlight dimming technology	Local Dimming
Noise reduction	Yes
Processor cores	4
USB recording	Yes

Ports & interfaces

Specification	Value
HDMI ports quantity	4
Audio Return Channel (ARC)	Yes
PC in (D-Sub)	No
DVI port	No
DVI-D ports quantity	0
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Digital audio optical out	1
Headphone outputs	1
RF ports quantity	3
Common interface Plus (CI+)	Yes
Common interface Plus (CI+) version	1.4
Consumer Electronics Control (CEC)	SimpLink

Management features

Specification	Value
Voice control	Yes
Electronic Programme Guide (EPG)	Yes
Programming period	8 day(s)
On Screen Display (OSD)	Yes
Number of OSD languages	36
On/Off timer	Yes
Sleep timer	Yes

Power

Specification	Value
Power consumption (typical)	205 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy saving mode	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C

Weight & dimensions

Specification	Value
Width (with stand)	1722 mm
Depth (with stand)	253 mm
Height (with stand)	1052 mm
Weight (with stand)	36.5 kg
Width (without stand)	1722 mm
Depth (without stand)	56 mm
Height (without stand)	991 mm
Weight (without stand)	29.9 kg

Packaging data

Specification	Value
Quick installation guide	Yes
Manual	Yes
Package width	1895 mm
Package depth	285 mm
Package height	1130 mm
Package weight	49.5 kg
Package type	Box

Packaging content

Specification	Value
Desktop stand	Yes
Cables included	AC
Remote control included	Yes
Remote control type	MR18

Other features

Specification	Value
Auto Depth Enhancer	Yes
Batteries included	Yes
Battery type	AA
Built-in speaker(s)	Yes
Twin tuner	Yes
Annual energy consumption	284 kWh
Digital Living Network Alliance (DLNA) certified	Yes
Energy efficiency class (legacy scale)	A
Operating relative humidity (H-H)	0 - 80%
Storage relative humidity (H-H)	0 - 85%
Storage temperature (T-T)	-20 - 60 °C
App store	LG Content Store
Smart Remote support	Yes
