dynaEdge DE-100-124
Model dynaEdge DE-100-124Part no. A1POC36E111YEAN 4051528380583
59 specifications
- ProcessorIntel® Core™ m5
- Memory4 GB
- Storage128 GB
- SpeedWi-Fi 5 (802.11ac)
- OSWindows 10 Pro
- Weight310 g
Overview
- Processor
- Intel® Core™ m5
- Memory
- 4 GB
- Storage
- 128 GB
- Speed
- Wi-Fi 5 (802.11ac)
- OS
- Windows 10 Pro
- Weight
- 310 g
- Brand
- Dynabook
- Category
- Stick PC
- Model
- dynaEdge DE-100-124
- Part number
- A1POC36E111Y
- EAN / UPC
- 4051528380583
- Also known as
- Dynabook dynaEdge DE-100-124 1.1 GHz Intel® Core™ m5 Windows 10 Pro White
Specifications
59 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 1.1 GHz |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ m5 |
| Processor generation | 6th gen Intel® Core™ m5 |
| Processor model | m5-6Y57 |
| Processor series | Intel Core m5-6Y Series |
| Processor boost frequency | 2.8 GHz |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor cache | 4 MB |
| Processor cache level | SmartCache |
| Processor lithography | 14 nm |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | LPDDR3 |
| Memory clock speed | 1600 MHz |
| Memory channels | Double-channel |
| Memory bandwidth (max) | 29.8 GB/s |
| Supported memory types | LPDDR3-SDRAM |
Storage
| Specification | Value |
|---|---|
| Internal storage capacity | 128 GB |
| Storage media | SSD |
| Memory card slot | Yes |
| Memory card type | MicroSD |
Graphics
| Specification | Value |
|---|---|
| Graphics card | HD Graphics 515 |
Network
| Specification | Value |
|---|---|
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB ports quantity | 2 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Audio connector type | Combo headphone/mic |
Design
| Specification | Value |
|---|---|
| Product colour | White |
Performance
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
| Embedded options available | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Certification | Le fabricant déclare que ce produit est compatible avec les directives CE et régulations suivantes. Le responsable pour toute certification CE est Dynabook Europe GmbH, Stresemannallee 4b, 41460 Neuss, Allemagne. |
Processor special features
| Specification | Value |
|---|---|
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Idle States | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Execute Disable Bit | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Power
| Specification | Value |
|---|---|
| Power source | AC adapter |
| AC adapter output voltage | 19 V |
| AC adapter output current | 2.37 A |
Battery
| Specification | Value |
|---|---|
| Number of battery cells | 2 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 165 mm |
| Depth | 85 mm |
| Height | 20 mm |
| Weight | 310 g |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | McAfee LiveSafe Microsoft Office |
| AC adapter included | Yes |
