Elite F1 S24F1S0 air conditioner Split system White

Model S24F1S0EAN 8720568103099

74 specifications

Overview

74 specifications in 6 groups

Specification	Value
Type	Split system
Product colour	White
Air conditioner functions	Cooling, Dehumidifying, Heating
Inverter technology	Yes
Comfort sleeping mode	Yes
Suitable for room area up to	45 m²
Thermostat range	16 - 31 °C
Seasonal efficiency rating (cooling) (SEER)	6.3
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
Cooling energy efficiency (EER, W/W)	3.4
Heating energy efficiency (COP, W/W)	3.9
Cooling capacity in watts (nominal)	7000 W
Cooling capacity in watts (min)	1500 W
Cooling capacity in watts (max)	7900 W
Heating capacity in watts (nominal) (Colder heating season)	7150 W
Heating capacity in watts (min)	1500 W
Heating capacity in watts (max)	8320 W
Cooling capacity (nominal)	24000 BTU/h
Built-in display	Yes
Refrigerating medium	R32
Refrigerating medium weight	1.2 kg
Compressor type	Rotary
Hose length (min)	5 m
Hose length (max)	25 m
Gas hose diameter	1.27 cm
Liquid hose diameter	6.35 mm
Dehumidifying capacity	1.8 l/h
Remotely operated	Yes
Operating temperature range indoor unit (cooling)	17 - 32 °C
Operating temperature range indoor unit (heating)	0 - 30 °C
Operating temperature range outdoor unit (cooling)	-15 - 53 °C
Operating temperature range outdoor unit (heating)	20 - 30 °C

Specification	Value
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (cooling)	389 kWh
Power consumption (cooling) (min)	420 W
Power consumption (cooling) (max)	2910 W
Power consumption (heating) (min)	420 W
Power consumption (heating) (max)	2890 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Current (cooling)	9.6 A
Current (heating)	8.6 A
Design load (cooling)	7 kW
Energy efficiency class (cooling) (legacy scale)	A++

Specification	Value
Indoor unit type	Wall-mountable
Indoor unit noise level (low speed)	33 dB
Indoor unit noise level (high speed)	46 dB
Indoor unit sound power level	56 dB
Cooling airflow (indoor unit)	1100 m³/h
Heating airflow (indoor unit)	1200 m³/h
Indoor units quantity	1
Indoor unit width	118.6 cm
Indoor unit depth	25.8 cm
Indoor unit height	34 cm
Indoor unit weight	17 kg
Indoor unit package width	126.5 cm
Indoor unit package depth	34.7 cm
Indoor unit package height	42 cm
Indoor unit package weight	20 kg

Specification	Value
Outdoor unit noise level	57 dB
Outdoor unit sound power level	67 dB
Cooling airflow (outdoor unit)	3000 m³/h
Heating airflow (outdoor unit)	3000 m³/h
Outdoor units quantity	1
Outdoor unit width	92 cm
Outdoor unit depth	38 cm
Outdoor unit height	69.9 cm
Outdoor unit weight	40 kg
Outdoor unit package width	94.9 cm
Outdoor unit package depth	39.2 cm
Outdoor unit package height	73.2 cm
Outdoor unit package weight	43 kg

Specification	Value
Remote control included	Yes

Specification	Value
Seasonal efficiency rating (heating) (SCOP)	4
