AR18BXFCAWKNEU + AR18BXFCAWKXEU

Model AR18BXFCAWKNEU + AR18BXFCAWKXEUPart no. F-AR18NEXEAN 8806092997530

84 specifications

Overview

Brand: Samsung
Category: Split-System Air Conditioner
Model: AR18BXFCAWKNEU + AR18BXFCAWKXEU
Part number: F-AR18NEX
EAN / UPC: 8806092997530
Also known as: Samsung Wind-Free Comfort Next AR18BXFCAWKNEU + AR18BXFCAWKXEU Split system White

84 specifications in 6 groups

Specification	Value
Type	Split system
Multi-split	No
Product colour	White
Air conditioner functions	Cooling, Dehumidifying, Heating
Inverter technology	Yes
Split system type	Mono split
Comfort sleeping mode	Yes
Seasonal efficiency rating (cooling) (SEER)	6.8
Seasonal efficiency rating (heating) (SCOP) (Warmer heating season)	4.8
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4.1
Cooling energy efficiency (EER, W/W)	3.6
Heating energy efficiency (COP, W/W)	3.73
Cooling capacity in watts (nominal)	5000 W
Cooling capacity in watts (min)	1600 W
Cooling capacity in watts (max)	6700 W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Heating capacity in watts (min)	1300 W
Heating capacity in watts (max)	8000 W
Cooling capacity (nominal)	17061 BTU/h
Cooling capacity (min)	5459 BTU/h
Cooling capacity (max)	22861 BTU/h
Heating capacity (nominal)	20473 BTU/h
Heating capacity (min)	4436 BTU/h
Heating capacity (max)	27297 BTU/h
Built-in display	Yes
Display type	LED
Timer	Yes
Timer duration (maximum)	24 h
Refrigerating medium	R32
Refrigerating medium weight	1.3 kg
Auto fan	Yes
Hose length (max)	30 m
Gas hose diameter	1.27 cm
Liquid hose diameter	6.35 mm
Air filter	Yes
Anti-bacterial filter	Yes
Dehumidifying capacity	2 l/h
Remotely operated	Yes
Smartphone/tablet remote support	Yes
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C

Specification	Value
Energy efficiency class (heating) (Average heating season)	A+
Energy efficiency class (heating) (Warmer heating season)	A++
Hourly energy consumption (cooling)	1390 kWh
Hourly energy consumption (heating)	1610 kWh
Annual energy consumption (cooling)	257 kWh
Annual energy consumption (heating) (Warmer heating season)	642 kWh
Annual energy consumption (heating) (Average heating season)	1298 kWh
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Current (cooling)	6.4 A
Current (heating)	7.8 A
Design load (cooling)	5 kW
Design load (heating) (Average heating season)	3.8 kW
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling) (legacy scale)	A++

Specification	Value
Wi-Fi	Yes

Specification	Value
Indoor unit type	Wall-mountable
Indoor unit noise level (low speed)	25 dB
Indoor unit noise level (high speed)	41 dB
Indoor unit sound power level	58 dB
Cooling airflow (indoor unit)	942 m³/h
Indoor units quantity	1
Indoor unit width	105.5 cm
Indoor unit depth	21.5 cm
Indoor unit height	29.9 cm
Indoor unit weight	12.2 kg
Indoor unit package width	111.5 cm
Indoor unit package depth	37.5 cm
Indoor unit package height	29 cm
Indoor unit package weight	14.7 kg

Specification	Value
Outdoor unit noise level	51 dB
Outdoor unit sound power level	65 dB
Outdoor units quantity	1
Outdoor unit width	88 cm
Outdoor unit depth	31 cm
Outdoor unit height	63.8 cm
Outdoor unit weight	39.7 kg
Outdoor unit package width	102.3 cm
Outdoor unit package depth	41.3 cm
Outdoor unit package height	72.4 cm
Outdoor unit package weight	42.7 kg

Specification	Value
Manual	Yes
Remote control included	Yes
