AR12NXCXAWKX Split system White
Model AR12NXCXAWKXPart no. AR12NXCXAWKXEUEAN 8801643090944
67 specifications
- Energy classA++
- TypeSplit system
- ColourWhite
- Wi-FiYes
- Indoor unit typeWall-mountable
- Outdoor unit noise level46 dB
Overview
- Energy class
- A++
- Type
- Split system
- Colour
- White
- Wi-Fi
- Yes
- Indoor unit type
- Wall-mountable
- Outdoor unit noise level
- 46 dB
- Brand
- Samsung
- Category
- Split-System Air Conditioner
- Model
- AR12NXCXAWKX
- Part number
- AR12NXCXAWKXEU
- EAN / UPC
- 8801643090944
- Also known as
- Samsung AR12NXCXAWKX Split system White
Specifications
67 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Type | Split system |
| Multi-split | No |
| Product colour | White |
| Air conditioner functions | Circulation, Cooling, Dehumidifying, Fan, Heating |
| Inverter technology | Yes |
| Ionizer | Yes |
| Comfort sleeping mode | Yes |
| Cooling energy efficiency (EER, W/W) | 3.68 |
| Heating energy efficiency (COP, W/W) | 3.74 |
| Cooling capacity in watts (nominal) | 3500 W |
| Cooling capacity in watts (min) | 750 W |
| Cooling capacity in watts (max) | 4000 W |
| Heating capacity in watts (nominal) (Warmer heating season) | 4000 W |
| Heating capacity in watts (min) | 620 W |
| Heating capacity in watts (max) | 5500 W |
| Cooling capacity (min) | 2559 BTU/h |
| Cooling capacity (max) | 11942 BTU/h |
| Heating capacity (min) | 2116 BTU/h |
| Heating capacity (max) | 13649 BTU/h |
| Built-in display | Yes |
| Refrigerating medium | R32 |
| Refrigerating medium weight | 850 g |
| Hose length (max) | 15 m |
| Air filter | Yes |
| Dehumidifying capacity | 1.5 l/h |
| Auto power off | Yes |
| Indication light | Yes |
| Smartphone/tablet remote support | Yes |
| Operating temperature (cooling) (T-T) | -10 - 46 °C |
| Operating temperature (heating) (T-T) | -15 - 24 °C |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (heating) (Average heating season) | A++ |
| Energy efficiency class (heating) (Colder heating season) | A++ |
| Energy efficiency class (heating) (Warmer heating season) | A++ |
| Hourly energy consumption (cooling) | 0.95 kWh |
| Hourly energy consumption (heating) | 1.07 kWh |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 Hz |
| Current (cooling) | 4.5 A |
| Current (heating) | 5.1 A |
| Energy efficiency class (cooling) (legacy scale) | A++ |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
Indoor unit
| Specification | Value |
|---|---|
| Indoor unit type | Wall-mountable |
| Indoor unit noise level (low speed) | 16 dB |
| Indoor unit noise level (high speed) | 40 dB |
| Indoor unit sound power level | 58 dB |
| Indoor units quantity | 1 |
| Indoor unit width | 82.8 cm |
| Indoor unit depth | 29.5 cm |
| Indoor unit height | 26.5 cm |
| Indoor unit weight | 11.3 kg |
| Indoor unit package width | 88.6 cm |
| Indoor unit package depth | 31.7 cm |
| Indoor unit package height | 33.5 cm |
| Indoor unit package weight | 13.9 kg |
Outdoor unit
| Specification | Value |
|---|---|
| Outdoor unit noise level | 46 dB |
| Outdoor units quantity | 1 |
| Outdoor unit width | 79 cm |
| Outdoor unit depth | 54.8 cm |
| Outdoor unit height | 28.5 cm |
| Outdoor unit weight | 31.1 kg |
| Outdoor unit package width | 91.3 cm |
| Outdoor unit package depth | 62.2 cm |
| Outdoor unit package height | 37.1 cm |
| Outdoor unit package weight | 33.2 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Remote control included | Yes |
| Warranty card | Yes |
