AR09TXFCAWKNEU + AR09TXFCAWKXEU
Model AR09TXFCAWKNEU + AR09TXFCAWKXEUPart no. F-AR09NXTEAN 8806090378935
83 specifications
- Energy classA+
- TypeSplit system
- ColourWhite
- Wi-FiYes
- Indoor unit typeWall-mountable
- Outdoor unit noise level46 dB
Overview
- Energy class
- A+
- Type
- Split system
- Colour
- White
- Wi-Fi
- Yes
- Indoor unit type
- Wall-mountable
- Outdoor unit noise level
- 46 dB
- Brand
- Samsung
- Category
- Split-System Air Conditioner
- Model
- AR09TXFCAWKNEU + AR09TXFCAWKXEU
- Part number
- F-AR09NXT
- EAN / UPC
- 8806090378935
- Also known as
- Samsung AR09TXFCAWKNEU + AR09TXFCAWKXEU Split system White
Specifications
83 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | Split system |
| Multi-split | No |
| Product colour | White |
| Air conditioner functions | Cooling, Dehumidifying, Fan, Heating |
| Inverter technology | Yes |
| Split system type | Mono split |
| Comfort sleeping mode | Yes |
| Suitable for room area up to | 25 m² |
| Seasonal efficiency rating (cooling) (SEER) | 6.7 |
| Seasonal efficiency rating (heating) (SCOP) (Warmer heating season) | 4.6 |
| Seasonal efficiency rating (heating) (SCOP) (Average heating season) | 4 |
| Cooling energy efficiency (EER, W/W) | 3.57 |
| Heating energy efficiency (COP, W/W) | 3.81 |
| Cooling capacity in watts (nominal) | 2500 W |
| Cooling capacity in watts (min) | 900 W |
| Cooling capacity in watts (max) | 3350 W |
| Heating capacity in watts (nominal) (Average heating season) | 3200 W |
| Heating capacity in watts (min) | 900 W |
| Heating capacity in watts (max) | 4500 W |
| Cooling capacity (nominal) | 8530 BTU/h |
| Cooling capacity (min) | 3071 BTU/h |
| Cooling capacity (max) | 11431 BTU/h |
| Heating capacity (nominal) | 10919 BTU/h |
| Heating capacity (min) | 3071 BTU/h |
| Heating capacity (max) | 15355 BTU/h |
| Built-in display | Yes |
| Timer | Yes |
| Timer duration (maximum) | 24 h |
| Refrigerating medium | R32 |
| Refrigerating medium weight | 700 g |
| Auto fan | Yes |
| Hose length (max) | 15 m |
| Gas hose diameter | 9.52 mm |
| Liquid hose diameter | 6.35 mm |
| Anti-bacterial filter | Yes |
| Dehumidifying capacity | 1 l/h |
| Remotely operated | Yes |
| Operating temperature (cooling) (T-T) | -10 - 46 °C |
| Operating temperature (heating) (T-T) | -15 - 24 °C |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (heating) (Average heating season) | A+ |
| Energy efficiency class (heating) (Warmer heating season) | A++ |
| Hourly energy consumption (cooling) | 0.7 kWh |
| Hourly energy consumption (heating) | 0.84 kWh |
| Annual energy consumption (cooling) | 131 kWh |
| Annual energy consumption (heating) (Warmer heating season) | 335 kWh |
| Annual energy consumption (heating) (Average heating season) | 735 kWh |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 Hz |
| Current (cooling) | 3.6 A |
| Current (heating) | 4 A |
| Design load (cooling) | 2.5 kW |
| Design load (heating) (Average heating season) | 2.1 kW |
| Design load (heating) (Warmer heating season) | 1.1 kW |
| Energy efficiency scale | A+++ to D |
| Energy efficiency class (cooling) (legacy scale) | A++ |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
Indoor unit
| Specification | Value |
|---|---|
| Indoor unit type | Wall-mountable |
| Indoor unit noise level (low speed) | 19 dB |
| Indoor unit noise level (high speed) | 37 dB |
| Indoor unit sound power level | 54 dB |
| Cooling airflow (indoor unit) | 618 m³/h |
| Indoor units quantity | 1 |
| Indoor unit width | 82 cm |
| Indoor unit depth | 21.5 cm |
| Indoor unit height | 29.9 cm |
| Indoor unit weight | 8.9 kg |
| Indoor unit package width | 88 cm |
| Indoor unit package depth | 37.5 cm |
| Indoor unit package height | 29 cm |
| Indoor unit package weight | 11.1 kg |
Outdoor unit
| Specification | Value |
|---|---|
| Outdoor unit noise level | 46 dB |
| Outdoor unit sound power level | 63 dB |
| Outdoor units quantity | 1 |
| Outdoor unit width | 66 cm |
| Outdoor unit depth | 24.2 cm |
| Outdoor unit height | 47.5 cm |
| Outdoor unit weight | 23 kg |
| Outdoor unit package width | 77.8 cm |
| Outdoor unit package depth | 33.1 cm |
| Outdoor unit package height | 55 cm |
| Outdoor unit package weight | 25 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
Other features
| Specification | Value |
|---|---|
| Seasonal efficiency rating (heating) (SCOP) | 4 |
