S12EQ.NSJ/S12EQ.UA3 air conditioner Split system White

Model S12EQ.NSJ/S12EQ.UA3EAN 8806098119202

73 specifications

Overview

73 specifications in 7 groups

Specification	Value
Type	Split system
Product colour	White
Air conditioner functions	Cooling, Heating
Inverter technology	Yes
Comfort sleeping mode	Yes
Thermostat range	-10 - 48 °C
Seasonal efficiency rating (cooling) (SEER)	6.6
Cooling energy efficiency (EER, W/W)	3.24
Heating energy efficiency (COP, W/W)	3.81
Cooling capacity in watts (nominal)	3500 W
Cooling capacity in watts (min)	890 W
Cooling capacity in watts (max)	4040 W
Heating capacity in watts (nominal) (Warmer heating season)	4000 W
Heating capacity in watts (nominal) (Average heating season)	890 W
Heating capacity in watts (nominal) (Colder heating season)	5100 W
Cooling capacity (min)	12000 BTU/h
Cooling capacity (max)	12000 BTU/h
Heating capacity (min)	12000 BTU/h
Heating capacity (max)	12000 BTU/h
Timer	Yes
Timer duration (maximum)	24 h
Refrigerating medium	R32
Hose length (min)	3 m
Hose length (max)	15 m
Gas hose diameter	9.52 mm
Drain hose diameter	2.15 cm
Liquid hose diameter	6.35 mm
Air filter	Yes
Dehumidifying capacity	1.3 l/h
Cord length	3 m
Remotely operated	Yes
Operating temperature (cooling) (T-T)	-10 - 48 °C
Operating temperature (heating) (T-T)	-10 - 48 °C

Specification	Value
Energy efficiency class (heating) (Average heating season)	A+
Hourly energy consumption (cooling)	3.5 kWh
Hourly energy consumption (heating)	2.5 kWh
Annual energy consumption (cooling)	186 kWh
Annual energy consumption (heating) (Average heating season)	875 kWh
Power consumption (cooling) (max)	1080 W
Power consumption (heating) (max)	1050 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Current	15 A
Design load (cooling)	3.5 kW
Design load (heating) (Average heating season)	2.5 kW
Design load (heating) (Colder heating season)	2.5 kW
Design load (heating) (Warmer heating season)	2.5 kW
Energy efficiency class (cooling) (legacy scale)	A++

Specification	Value
Indoor unit type	Wall-mountable
Indoor unit noise level (low speed)	27 dB
Indoor unit noise level (high speed)	41 dB
Indoor unit sound power level	35 dB
Cooling airflow (indoor unit)	2700 m³/h
Heating airflow (indoor unit)	2700 m³/h
Indoor units quantity	1
Indoor unit width	83.7 cm
Indoor unit depth	18.9 cm
Indoor unit height	30.8 cm
Indoor unit weight	8.7 kg

Specification	Value
Outdoor unit noise level	50 dB
Outdoor unit sound power level	65 dB
Cooling airflow (outdoor unit)	1620 m³/h
Heating airflow (outdoor unit)	1620 m³/h
Outdoor units quantity	1
Outdoor unit width	71.7 cm
Outdoor unit depth	23 cm
Outdoor unit height	48.3 cm
Outdoor unit weight	25.1 kg

Specification	Value
Certification	ECC

Specification	Value
Seasonal efficiency rating (heating) (SCOP)	4
