CBYR0903W + CBYR0903G

Model CBYR0903W + CBYR0903GPart no. KITCBYR09

66 specifications

Overview

66 specifications in 6 groups

Specification	Value
Type	Split system
Multi-split	No
Product colour	White
Air conditioner functions	Cooling, Dehumidifying, Heating
Seasonal efficiency rating (cooling) (SEER)	6.1
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
Cooling energy efficiency (EER, W/W)	3.04
Heating energy efficiency (COP, W/W)	3.9
Cooling capacity in watts (nominal)	2600 W
Cooling capacity in watts (min)	1000 W
Cooling capacity in watts (max)	3000 W
Heating capacity in watts (nominal) (Average heating season)	2700 W
Heating capacity in watts (min)	1000 W
Heating capacity in watts (max)	3000 W
Built-in display	Yes
Display type	LED
Timer	Yes
Refrigerating medium	R32
Hose length (max)	20 m
Gas hose diameter	9.52 mm
Liquid hose diameter	6.35 mm
Air filter	Yes
Dehumidifying capacity	0.9 l/h
Remotely operated	Yes
Smartphone/tablet remote support	Yes
Maximum number of indoor units	1
Operating temperature (cooling) (T-T)	-15 - 43 °C
Operating temperature (heating) (T-T)	-15 - 24 °C

Specification	Value
Energy efficiency class (heating) (Average heating season)	A+
Energy efficiency class (heating) (Warmer heating season)	A+++
Annual energy consumption (cooling)	149 kWh
Annual energy consumption (heating) (Warmer heating season)	659 kWh
Annual energy consumption (heating) (Average heating season)	700 kWh
Power consumption (cooling) (min)	200 W
Power consumption (cooling) (max)	1500 W
Power consumption (heating) (min)	200 W
Power consumption (heating) (max)	1500 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Current	7.5 A
Current (cooling)	3.9 A
Current (heating)	3.1 A
Design load (cooling)	2.6 kW
Design load (heating) (Average heating season)	2 kW
Design load (heating) (Warmer heating season)	2.4 kW
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling) (legacy scale)	A++

Specification	Value
Wi-Fi	Yes
Bluetooth	No

Specification	Value
Indoor unit type	Wall-mountable
Indoor unit noise level (low speed)	24 dB
Indoor unit noise level (high speed)	39 dB
Indoor unit sound power level	56 dB
Cooling airflow (indoor unit)	540 m³/h
Indoor units quantity	1
Indoor unit width	79 cm
Indoor unit depth	19.7 cm
Indoor unit height	25.5 cm
Indoor unit weight	7.1 kg

Specification	Value
Manual	Yes
Remote control included	Yes
