ACY 71 UIA-LM

Model ACY 71 UIA-LMPart no. 3NGF8405EAN 8432884200276

52 specifications

Overview

52 specifications in 6 groups

Specification	Value
Type	Split system
Multi-split	Yes
Product colour	Grey, White
Air conditioner functions	Cooling, Heating
Inverter technology	Yes
Ionizer	No
Seasonal efficiency rating (cooling) (SEER)	6.2
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
Cooling capacity in watts (nominal)	6800 W
Cooling capacity in watts (min)	900 W
Cooling capacity in watts (max)	8000 W
Heating capacity in watts (nominal) (Average heating season)	8000 W
Heating capacity in watts (min)	900 W
Heating capacity in watts (max)	9100 W
Compressor type	Rotary
Compressor motor type	Brushless
Hose length (min)	15 m
Hose length (max)	20 m
Gas hose diameter	1.59 cm
Liquid hose diameter	6.35 mm
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C

Specification	Value
Energy efficiency class (heating) (Average heating season)	A+
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Current (cooling)	12 A
Current (heating)	13.5 A
Design load (cooling)	2.21 kW
Design load (heating) (Average heating season)	2.26 kW
Energy efficiency class (cooling) (legacy scale)	A++

Specification	Value
Wi-Fi	No

Specification	Value
Indoor unit type	Ceiling
Indoor unit noise level (low speed)	27 dB
Indoor unit noise level (high speed)	31 dB
Indoor unit sound power level	29 dB
Cooling airflow (indoor unit)	1100 m³/h
Heating airflow (indoor unit)	1100 m³/h
Indoor units quantity	1
Indoor unit width	113.5 cm
Indoor unit depth	70 cm
Indoor unit height	27 cm
Indoor unit weight	38 kg

Specification	Value
Outdoor unit noise level	52 dB
Outdoor unit sound power level	52 dB
Cooling airflow (outdoor unit)	2470 m³/h
Heating airflow (outdoor unit)	2470 m³/h
Outdoor units quantity	1
Outdoor unit width	79.9 cm
Outdoor unit depth	29 cm
Outdoor unit height	63.2 cm
Outdoor unit weight	44 kg

Specification	Value
Manual	Yes
