S S522W soundbar speaker Black 2.1 channels
200 W
Model S522WEAN 8720568100524
79 specifications
- ConnectivityWireless
- ColourBlack
- Audio output channels2.1 channels
- Soundbar speaker RMS power40 W
- Subwoofer includedYes
- Pallet net height2 m
Overview
- Connectivity
- Wireless
- Colour
- Black
- Audio output channels
- 2.1 channels
- Soundbar speaker RMS power
- 40 W
- Subwoofer included
- Yes
- Pallet net height
- 2 m
- Brand
- TCL
- Category
- Soundbar Speakers
- Model
- S522W
- Part number
- S522W
- EAN / UPC
- 8720568100524
- Also known as
- TCL S S522W soundbar speaker Black 2.1 channels 200 W
Specifications
79 specifications in 13 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 2.1 channels |
| RMS rated power | 200 W |
| Equalizer | Yes |
| Audio Return Channel (ARC) | Yes |
Soundbar speaker
| Specification | Value |
|---|---|
| Soundbar speaker RMS power | 40 W |
| Tweeter diameter (imperial) | 5.71 cm (2.25") |
Subwoofer
| Specification | Value |
|---|---|
| Subwoofer included | Yes |
| Subwoofer connectivity | Wireless |
| Subwoofer RMS power | 30 W |
| Woofer diameter (subwoofer) | 13.3 cm (5.25") |
| Subwoofer location | Separate |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Built-in display | Yes |
| Display type | LED |
| Audio formats supported | MP3, WAV, WMA |
| Auto power off | Yes |
| On/off switch | Yes |
| Volume control | Buttons |
| Wall mountable | Yes |
| LED indicators | Yes |
Technical details
| Specification | Value |
|---|---|
| Pallet net height | 2 m |
| Pallet net length | 100 cm |
| Pallet net width | 120 cm |
| Chemical tax (Sweden) | Yes |
| Chemical tax reduction (Sweden) | 0 |
| USB playback | Yes |
| Warranty period | 2 year(s) |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wireless |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Wi-Fi | No |
| Ethernet LAN | No |
| HDMI ports quantity | 1 |
| USB port | Yes |
| Digital audio coaxial in | 0 |
| Digital audio optical in | 1 |
| AUX in | Yes |
| Digital audio optical out | 0 |
| Headphone outputs | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 / 60 Hz |
| Soundbar power consumption | 9 W |
| Subwoofer power consumption | 10 W |
| Power consumption (typical) | 19 W |
| Power consumption (standby) | 1 W |
Battery
| Specification | Value |
|---|---|
| Battery weight | 15 g |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 800 mm |
| Depth | 99 mm |
| Height | 70 mm |
| Soundbar weight | 1.1 kg |
| Subwoofer width | 16.5 cm |
| Subwoofer depth | 29.8 cm |
| Subwoofer height | 24 cm |
| Subwoofer weight | 2.26 kg |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
| Wall mounting kit | Yes |
| Cables included | AC, RCA |
| Remote control included | Yes |
| Batteries included | Yes |
| Quick start guide | Yes |
| Warranty card | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 842 mm |
| Package depth | 207 mm |
| Package height | 380 mm |
| Package weight | 4.96 kg |
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross length | 120 cm |
| Pallet gross height | 2 m |
| Pallet gross weight | 221 kg |
| Pallet net weight | 221 kg |
| Products per pallet | 28 pc(s) |
| Master (outer) cases per pallet | 50 pc(s) |
| Truck type | 87cbm |
| Quantity per truck | 728 pc(s) |
| Number of pallets per truck | 26 pc(s) |
Other features
| Specification | Value |
|---|---|
| Number of remote control batteries | 1 |
| Remote control battery technology | Lithium |
| Remote control battery type | CR2025 |
