Q Q75H Class 5.1.2 Channel Sound Bar with Dolby Atmos, Ray Danz Technology, and Wireless Subwoofwer
Model Q75HPart no. TCLQ75HEAN 6921732887346
108 specifications
- ConnectivityWired & Wireless
- Weight6.4 kg
- ColourTitanium
- Audio output channels5.1.2 channels
- Soundbar speaker RMS power30 W
- Subwoofer includedYes
Overview
- Connectivity
- Wired & Wireless
- Weight
- 6.4 kg
- Colour
- Titanium
- Audio output channels
- 5.1.2 channels
- Soundbar speaker RMS power
- 30 W
- Subwoofer included
- Yes
- Brand
- TCL
- Category
- Soundbar Speakers
- Model
- Q75H
- Part numbers
- TCLQ75H, Q75HE, Q75H
- EAN / UPC
- 6921732887346, 8720568106045, 703670909436, 846042091206
- Also known as
- TCL Q Q75H Class 5.1.2 Channel Sound Bar with Dolby Atmos, Ray Danz Technology, and Wireless Subwoofwer
Specifications
108 specifications in 12 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 5.1.2 channels |
| RMS rated power | 620 W |
| Audio decoders | DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital Plus, Dolby MAT, Dolby Surround, Dolby TrueHD |
| Soundbar mode control | Yes |
| TV Sound Share | Yes |
| Equalizer | Yes |
| Equalizer modes | Game, Movie, Music, Sport, Standard, Voice |
| Audio Return Channel (ARC) | Yes |
| Enhanced Audio Return Channel (eARC) | Yes |
| Audio sample rate (24bit) | 48 kHz |
Soundbar speaker
| Specification | Value |
|---|---|
| Soundbar speaker RMS power | 30 W |
| Number of speakers | 11 |
Subwoofer
| Specification | Value |
|---|---|
| Subwoofer included | Yes |
| Subwoofer connectivity | Wireless |
| Subwoofer type | Active subwoofer |
| Subwoofer RMS power | 100 W |
| Bass adjustment | Yes |
| Woofer diameter (subwoofer) | 20.3 cm (8") |
| Subwoofer location | Separate |
Features
| Specification | Value |
|---|---|
| Product colour | Titanium |
| Colour name | Dark titanium |
| FM radio | No |
| High Dynamic Range (HDR) technology | Dolby Vision |
| Built-in display | Yes |
| Display type | LED |
| USB direct playback | Yes |
| Apple AirPlay 2 support | Yes |
| Audio formats supported | AAC, MP3 |
| Network streaming services supported | Chromecast, Spotify |
| Supported video streaming resolutions | 4096 x 2160 |
| Consumer Electronics Control (CEC) | T-link |
| Spotify Connect | Yes |
| Built-in Chromecast | Yes |
| Night mode | Yes |
| Auto power off | Yes |
| On/off switch | Yes |
| Quick power on | Yes |
| Sleep timer | No |
| Detachable power cord | Yes |
| Smartphone/tablet remote support | Yes |
| Supported radio bands | Not supported |
| Virtual surround | Yes |
| Plug and Play | Yes |
| Wall mountable | Yes |
Technical details
| Specification | Value |
|---|---|
| 3D | Yes |
| Video formats supported | Not supported |
| Warranty period | 2 year(s) |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Bluetooth codec | A2DP, AVRCP, SBC, AAC |
| Wi-Fi | Yes |
| Wi-Fi ready | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN | No |
| HDMI ports quantity | 2 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 2.1 |
| HDCP | Yes |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Composite video in | 0 |
| Card reader integrated | No |
| Digital audio coaxial in | 0 |
| Compatible memory cards | Not supported |
| Digital audio coaxial out | 0 |
| Digital audio optical in | 1 |
| AUX in | No |
| Digital audio optical out | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 98 W |
| Power consumption (standby) | 1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1040 mm |
| Depth | 110 mm |
| Height | 58 mm |
| Weight | 6.4 kg |
| Soundbar weight | 5.6 kg |
| Subwoofer width | 22 cm |
| Subwoofer depth | 27.5 cm |
| Subwoofer height | 36.9 cm |
| Subwoofer weight | 5.6 kg |
| Cord length | 1.5 m |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 2 pc(s) |
| Receiver included | Yes |
| Wall mounting kit | Yes |
| Cables included | AC, HDMI |
| Mounting brackets included | Yes |
| Remote control included | Yes |
| Batteries included | Yes |
| Quick start guide | Yes |
| Warranty card | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1138 mm |
| Package depth | 512 mm |
| Package height | 292 mm |
| Package weight | 15.2 kg |
| Package type | Carton |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross width | 120 cm |
| Pallet gross length | 180 cm |
| Pallet gross height | 80 cm |
| Products per pallet | 10 pc(s) |
| Quantity per truck | 330 pc(s) |
| Number of pallets per truck | 33 pc(s) |
Other features
| Specification | Value |
|---|---|
| Optical disc player type | Not included |
| Digital Living Network Alliance (DLNA) certified | No |
| Remote control battery technology | Alkaline |
