Bar 500MK2
Model Bar 500MK2Part no. JBLBAR500M2WHTAS2EAN 1200130020568
39 specifications
- ConnectivityWired & Wireless
- ColourWhite
- Audio output channels5.1 channels
- Soundbar speaker RMS power450 W
- Subwoofer includedYes
- AC input voltage100–240
Overview
- Connectivity
- Wired & Wireless
- Colour
- White
- Audio output channels
- 5.1 channels
- Soundbar speaker RMS power
- 450 W
- Subwoofer included
- Yes
- AC input voltage
- 100–240
- Brand
- JBL
- Category
- Soundbar Speakers
- Model
- Bar 500MK2
- Part numbers
- JBLBAR500M2WHTAS2, JBLBAR500M2BLKAS2, JBLBAR500M2BLKEP
- EAN / UPC
- 1200130020568, 1200130020612, 1200130020605
- Also known as
- JBL Bar 500MK2 White 5.1 channels 750 W
Specifications
39 specifications in 8 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 5.1 channels |
| RMS rated power | 750 W |
| Audio decoders | Dolby Atmos, DTS Virtual:X |
| Enhanced Audio Return Channel (eARC) | Yes |
Soundbar speaker
| Specification | Value |
|---|---|
| Soundbar speaker RMS power | 450 W |
| Number of tweeter drivers | 4 |
| Tweeter diameter (imperial) | 1.91 cm (0.75") |
| Tweeter diameter | 2 cm |
Subwoofer
| Specification | Value |
|---|---|
| Subwoofer included | Yes |
| Subwoofer RMS power | 300 W |
| Woofer diameter (subwoofer) | 25.4 cm (10") |
Features
| Specification | Value |
|---|---|
| Product colour | White |
| High Dynamic Range (HDR) technology | Dolby Vision |
| Audio formats supported | MP3 |
| Operating temperature (T-T) | 0 - 45 °C |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| HDMI ports quantity | 1 |
| HDCP | Yes |
| HDCP version | 2.3 |
| USB port | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100–240 |
| AC input frequency | 50/60 Hz |
| Power consumption (standby) | 2 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 940 mm |
| Depth | 104 mm |
| Height | 50.5 mm |
| Soundbar weight | 2.9 kg |
| Subwoofer width | 32.5 cm |
| Subwoofer depth | 32.5 cm |
| Subwoofer height | 40 cm |
| Subwoofer weight | 8.1 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1030 mm |
| Package depth | 403 mm |
| Package height | 487 mm |
| Package weight | 18 kg |
