HSD310S5 3.1
Model HSD310S5 3.1Part no. 36200102EAN 6976454832280
70 specifications
- ConnectivityWired & Wireless
- ColourBlack, Grey
- Audio output channels3.1 channels
- Soundbar speaker RMS power120 W
- Subwoofer includedYes
- 3DNo
Overview
- Connectivity
- Wired & Wireless
- Colour
- Black, Grey
- Audio output channels
- 3.1 channels
- Soundbar speaker RMS power
- 120 W
- Subwoofer included
- Yes
- 3D
- No
- Brand
- Haier
- Category
- Soundbar Speakers
- Model
- HSD310S5 3.1
- Part number
- 36200102
- EAN / UPC
- 6976454832280
- Also known as
- Haier HSD310S5 3.1 Black, Grey 3.1 channels 240 W
Specifications
70 specifications in 11 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 3.1 channels |
| RMS rated power | 240 W |
| Audio decoders | Dolby Atmos, Dolby Audio |
| Equalizer | Yes |
| Audio Return Channel (ARC) | Yes |
| Enhanced Audio Return Channel (eARC) | Yes |
Soundbar speaker
| Specification | Value |
|---|---|
| Soundbar speaker RMS power | 120 W |
| Number of speakers | 7 |
| Number of tweeter drivers | 3 |
| Number of full-range drivers | 5 |
| Tweeter diameter (imperial) | 3.81 cm (1.5") |
Subwoofer
| Specification | Value |
|---|---|
| Subwoofer included | Yes |
| Subwoofer connectivity | Wireless |
| Subwoofer type | Passive subwoofer |
| Subwoofer RMS power | 120 W |
| Subwoofer frequency range | 40 - 120 Hz |
| Subwoofer impedance | 74 Ω |
| Woofer diameter (subwoofer) | 16.5 cm (6.5") |
Features
| Specification | Value |
|---|---|
| Product colour | Black, Grey |
| FM radio | No |
| Smartphone/tablet remote support | Yes |
| Supported radio bands | Not supported |
| Wall mountable | Yes |
Technical details
| Specification | Value |
|---|---|
| 3D | No |
| Compliance certificates | CB, CE |
| Video formats supported | AVI, DIVX, MKV, MP4 |
| Warranty period | 2 year(s) |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Wi-Fi | No |
| Ethernet LAN | No |
| HDMI ports quantity | 3 |
| USB port | Yes |
| Composite video in | 0 |
| Card reader integrated | No |
| Digital audio coaxial in | 0 |
| Compatible memory cards | Not supported |
| Digital audio coaxial out | 1 |
| Digital audio optical in | 0 |
| AUX in | Yes |
| Digital audio optical out | 1 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| Soundbar power consumption | 120 W |
| Subwoofer power consumption | 120 W |
| Power consumption (typical) | 240 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 966 mm |
| Depth | 101.5 mm |
| Height | 66 mm |
| Soundbar weight | 5.12 kg |
| Subwoofer width | 24 cm |
| Subwoofer depth | 24 cm |
| Subwoofer height | 42 cm |
| Subwoofer weight | 3.65 kg |
| Cord length | 1.5 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, Audio (3.5mm), HDMI |
| Mounting brackets included | Yes |
| Remote control included | Yes |
| Batteries included | Yes |
| Quick start guide | Yes |
| Warranty card | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1140 mm |
| Package depth | 515 mm |
| Package height | 285 mm |
| Package weight | 12.8 kg |
Other features
| Specification | Value |
|---|---|
| Frequency range | 120 - 20000 Hz |
| Optical disc player type | Not included |
| Soundbar speaker housing material | Metal/Plastic |
| AC adapter included | Yes |
| Digital Living Network Alliance (DLNA) certified | No |
