17" LCD KVM Rack Console, English K/B
Model KVM-0117USEAN 4015867133293
43 specifications
- Display43.2 cm (17")
- Resolution1280 x 1024 pixels
- Weight11.8 kg
- ColourBlack
- Horizontal scan range45 - 80 kHz
- Rack capacity1U
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1280 x 1024 pixels
- Weight
- 11.8 kg
- Colour
- Black
- Horizontal scan range
- 45 - 80 kHz
- Rack capacity
- 1U
- Brand
- LevelOne
- Category
- Rack Console
- Model
- KVM-0117US
- Part number
- KVM-0117US
- EAN / UPC
- 4015867133293
- Also known as
- LevelOne 17" LCD KVM Rack Console, English K/B
Specifications
43 specifications in 11 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| Display | TFT |
| Contrast ratio (typical) | 400:1 |
| Display brightness | 250 cd/m² |
| Display number of colours | 16.78 million colours |
| Display type | LCD |
| On Screen Display (OSD) | Yes |
| Pixel pitch | 0.297 x 0.297 mm |
| Rise time | 2 ms |
| Viewing angle, horizontal | 70° |
| Viewing angle, vertical | 60° |
Scanning frequency
| Specification | Value |
|---|---|
| Horizontal scan range | 45 - 80 kHz |
Technical details
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Operating relative humidity (H-H) | 10 - 90% |
| Product colour | Black |
| Country of origin | Taiwan |
Ports & interfaces
| Specification | Value |
|---|---|
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | DVI/VGA |
Keyboard
| Specification | Value |
|---|---|
| Built-in touchpad | Yes |
| Keyboard language | US English |
| Keyboard layout | QWERTY |
| Keyboard number of keys | 106 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 25 W |
| Power consumption (standby) | 25 W |
| AC adapter input voltage | 100 - 240 V |
System requirements
| Specification | Value |
|---|---|
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 447.5 mm |
| Height | 44 mm |
| Depth | 482 mm |
| Weight | 11.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 17.6 kg |
| Package width | 560 mm |
| Package depth | 190 mm |
| Package height | 660 mm |
Packaging content
| Specification | Value |
|---|---|
| Keys quantity | 2 keys |
| Screws included | Yes |
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
| Manual | Yes |
