ATEN 8-Port 19" LCD KVM Switch (USB - PS/2 VGA) with USB Peripheral port (Dual Rail)
ATEN

8-Port 19" LCD KVM Switch (USB - PS/2 VGA) with USB Peripheral port (Dual Rail)

Model CL5808N-ATA-AGEAN 4710469345555

68 specifications
  • Display48.3 cm (19")
  • Resolution1280 x 1024 pixels
  • Weight14.5 kg
  • ColourBlack
  • Rack capacity1U
  • VGA (D-Sub) ports quantity1
See all specifications

Overview

Display
48.3 cm (19")
Resolution
1280 x 1024 pixels
Weight
14.5 kg
Colour
Black
Rack capacity
1U
VGA (D-Sub) ports quantity
1
Brand
ATEN
Category
Rack Console
Model
CL5808N-ATA-AG
Part number
CL5808N-ATA-AG
EAN / UPC
4710469345555, 4719264642531
Also known as
ATEN 8-Port 19" LCD KVM Switch (USB - PS/2 VGA) with USB Peripheral port (Dual Rail)

Specifications

68 specifications in 11 groups

Display

Display diagonal48.3 cm (19")
Display resolution1280 x 1024 pixels
DisplayLCD
Contrast ratio (typical)1000:1
Display brightness250 cd/m²
Display typeTFT
On Screen Display (OSD)Yes
Pixel pitch0.294 x 0.294 mm
Response time5 ms
Viewing angle, horizontal170°
Viewing angle, vertical160°
Supported resolutions1280 x 1024 @75 Hz; DDC2B, 1920 x 1200 @ 60 Hz

Technical details

Rack capacity1U
MaterialMetal, Plastic
Auto scan delay (max)255 s
Auto scan delay (min)1 s
Built-in KVM switchYes
Compliance certificatesRoHS
Console portSPHD-18
Daisy chainYes
Hot-Plug supportYes
KVM switch ports quantity8
LED indicatorsYes
Maximum resolution1920 x 1200 pixels
Number of computers controlled256
On/off switchYes
Operating relative humidity (H-H)0 - 80%
Product colourBlack
Push buttonYes
Rack mountingYes

Ports & interfaces

VGA (D-Sub) ports quantity1
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
USB 2.0 Type-A ports quantity3
I/O ports1x RJ-11 1x DB-25 8x SPHD-17/18

Keyboard

Built-in touchpadYes
Hot keysYes
Keyboard languageUS English
Keyboard layoutQWERTY

System requirements

Windows operating systems supportedYes
Mac operating systems supportedYes
Linux operating systems supportedYes

Power

Power consumption (typical)25 W
AC adapter input voltage100 - 240 V
AC adapter frequency50/60 Hz
Input current1 A
AC (power) inYes

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width680.4 mm
Height44 mm
Depth480 mm
Weight14.5 kg

Packaging data

Package weight18.6 kg
Package width668 mm
Package depth833 mm
Package height135 mm

Packaging content

Cables includedAC, KVM
Quick installation guideYes
ManualYes
Rack mount kitYes

Logistics data

Master (outer) case net weight15.4 kg
Master (outer) case width668 mm
Master (outer) case length833 mm
Master (outer) case height135 mm
Master (outer) case gross weight18.6 kg
Products per master (outer) case1 pc(s)
