17" LCD KVM Rack Console, French K/B
Model KVM-0117FREAN 4015867133729
37 specifications
- Display43.2 cm (17")
- Resolution1280 x 1024 pixels
- ColourBlack
- Horizontal scan range45 - 80 kHz
- DVI input ports1
- Built-in touchpadYes
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1280 x 1024 pixels
- Colour
- Black
- Horizontal scan range
- 45 - 80 kHz
- DVI input ports
- 1
- Built-in touchpad
- Yes
- Brand
- LevelOne
- Category
- Rack Console
- Model
- KVM-0117FR
- Part number
- KVM-0117FR
- EAN / UPC
- 4015867133729
- Also known as
- LevelOne 17" LCD KVM Rack Console, French K/B
Specifications
37 specifications in 11 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| Display | TFT |
| Contrast ratio (typical) | 400:1 |
| Display brightness | 250 cd/m² |
| Display number of colours | 16.194 million colours |
| On Screen Display (OSD) | Yes |
| Pixel pitch | 0.297 x 0.297 mm |
| Response time | 14 ms |
| Rise time | 2 ms |
| Viewing angle, horizontal | 10° |
| Viewing angle, vertical | 15° |
Scanning frequency
| Specification | Value |
|---|---|
| Horizontal scan range | 45 - 80 kHz |
Technical details
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| DVI input ports | 1 |
| Keyboard port type | PS/2 |
| Mouse port type | PS/2 |
| USB 2.0 Type-A ports quantity | 1 |
| I/O ports | PS/2, USB, DVI |
Keyboard
| Specification | Value |
|---|---|
| Built-in touchpad | Yes |
| Keyboard number of keys | 106 |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 2000, Windows ME, Windows NT, Windows XP |
| Server operating systems supported | Windows Server 2003 |
| Linux operating systems supported | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 25 W |
| AC adapter input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 17.6 kg |
| Package width | 560 mm |
| Package depth | 190 mm |
| Package height | 660 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, KVM, USB |
| Quick installation guide | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 1 pc(s) |
