KL9116 rack console
43.2 cm (17") 1600 x 1200 pixels Metal 1U
Model KL9116
21 specifications
- Display43.2 cm (17")
- Resolution1600 x 1200 pixels
- Rack capacity1U
- Built-in touchpadYes
- Power supply typeAC
- Operating temperature (T-T)0 - 40 °C
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1600 x 1200 pixels
- Rack capacity
- 1U
- Built-in touchpad
- Yes
- Power supply type
- AC
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- ATEN
- Category
- Rack Console
- Model
- KL9116
- Part number
- KL9116
- Also known as
- ATEN KL9116 rack console 43.2 cm (17") 1600 x 1200 pixels Metal 1U
Specifications
21 specifications in 6 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1600 x 1200 pixels |
| Display | LCD |
| On Screen Display (OSD) | Yes |
Technical details
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Material | Metal |
| Built-in KVM switch | Yes |
| KVM switch ports quantity | 16 |
| LED indicators | Yes |
| Rack mounting | Yes |
| Relative humidity | 0 - 80% |
| Security algorithms | 256-bit AES, 802.1x RADIUS, DES, HTTPS, RSA, SSL/TLS |
Keyboard
| Specification | Value |
|---|---|
| Built-in touchpad | Yes |
Power
| Specification | Value |
|---|---|
| Power supply type | AC |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 482 mm |
| Height | 44 mm |
| Depth | 706.3 mm |
