ATEN 8-Port 17.3" DVI Full HD LCD KVM Switch (USB)
ATEN

8-Port 17.3" DVI Full HD LCD KVM Switch (USB)

Model CL6708MW-ATA-AGEAN 672792006845

60 specifications
  • Display43.9 cm (17.3")
  • Resolution1920 x 1080 pixels
  • Weight12.7 kg
  • ColourBlack
  • Rack capacity1U
  • 3.5 mm (1/8-inch) outYes
See all specifications

Overview

Display
43.9 cm (17.3")
Resolution
1920 x 1080 pixels
Weight
12.7 kg
Colour
Black
Rack capacity
1U
3.5 mm (1/8-inch) out
Yes
Brand
ATEN
Category
Rack Console
Model
CL6708MW-ATA-AG
Part number
CL6708MW-ATA-AG
EAN / UPC
672792006845, 4710469345586, 4719264643804
Also known as
ATEN 8-Port 17.3" DVI Full HD LCD KVM Switch (USB)

Specifications

60 specifications in 9 groups

Display

Display diagonal43.9 cm (17.3")
Display resolution1920 x 1080 pixels
DisplayLCD
Aspect ratio16:9
Contrast ratio (typical)800:1
Display brightness250 cd/m²
Display typeTFT
On Screen Display (OSD)Yes
Pixel pitch0.1989 x 0.1989 mm
Response time16 ms
Viewing angle, horizontal170°
Viewing angle, vertical170°
Supported resolutionsup to 1920 x 1200 @ 60 Hz (all resolution @ 60 Hz only); 1920 x 1080 @ 60 Hz, DDC2B

Technical details

Rack capacity1U
MaterialMetal, Plastic
Built-in KVM switchYes
Compliance certificatesRoHS
Hot-Plug supportYes
LED indicatorsYes
Maximum resolution1920 x 1200 pixels
Number of computers controlled64
On/off switchYes
Operating relative humidity (H-H)0 - 80%
Product colourBlack
Push buttonYes
Rack mountingYes

Ports & interfaces

3.5 mm (1/8-inch) outYes
3.5 mm (1/8-inch) inYes
DVI connector typeDVI-I
DVI input ports1
DVI output ports8
Keyboard port typeUSB
Mouse port typeUSB
USB 2.0 Type-A ports quantity3
USB 2.0 Type-B ports quantity8
I/O ports1x RJ-11

Keyboard

Built-in touchpadYes
Hot keysYes
Keyboard languageUS English
Keyboard layoutQWERTY

System requirements

Windows operating systems supportedYes
Mac operating systems supportedYes
Linux operating systems supportedYes
Other operating systems supportedYes

Power

Power consumption (typical)29.26 W
AC adapter input voltage100 - 240 V
AC adapter frequency50/60 Hz
Input current1 A
AC (power) inYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width689.2 mm
Height44 mm
Depth480 mm
Weight12.7 kg

Packaging content

Cables includedAC, KVM
Quick installation guideYes
ManualYes
AC adapter includedYes
Rack mount kitYes
