LVR300132 rack cabinet 32U Maple colour
Model LVR300132EAN 5704174990574
45 specifications
- Noise30 dB
- Weight124 kg
- ColourMaple colour
- Rack capacity32U
- Width750 mm
- Compliance certificatesRoHS
Overview
- Noise
- 30 dB
- Weight
- 124 kg
- Colour
- Maple colour
- Rack capacity
- 32U
- Width
- 750 mm
- Compliance certificates
- RoHS
- Brand
- Lanview
- Category
- Rack Cabinet
- Model
- LVR300132
- Part number
- LVR300132
- EAN / UPC
- 5704174990574
- Also known as
- Lanview LVR300132 rack cabinet 32U Maple colour
Specifications
45 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Rack capacity | 32U |
| Maximum weight capacity | 1500 kg |
| Maximum weight capacity (rolling) | 750 kg |
| Product colour | Maple colour |
| Material | Wood |
| Back door construction | Steel |
| Front door construction | Wood veneer |
| Side panel construction | Steel |
| Removable back door | No |
| Removable front door | No |
| Removable side panels | Yes |
| Side panels included | Yes |
| Key lock | Yes |
| Back door key lock | Yes |
| Side panel key lock | Yes |
| Rack rails | Yes |
| Adjustable depth | Yes |
| Adjustable mounting rails | Yes |
| Adjustable stand | No |
| Adjustable feet | Yes |
| Cooling - rack front door | 6 fans |
| Cooling agent | active cooling |
| Number of fans | 6 fan(s) |
| Noise level | 30 dB |
| Soundproof | Yes |
| Cable management | Yes |
| Castor wheels | Yes |
| Assembly required | No |
| International Protection (IP) code | IP20 |
| Preassembled | Yes |
| Certification | UL, TUV, CE, ISO 9001, EN 67587-1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 750 mm |
| Depth | 1130 mm |
| Height | 1000 mm |
| Weight | 124 kg |
Packaging data
| Specification | Value |
|---|---|
| Nuts included | Yes |
| Manual | Yes |
| Package width | 820 mm |
| Package depth | 1200 mm |
| Package height | 1120 mm |
| Package weight | 130 kg |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Turkey |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 750 x 1130 x 1666 mm |
| Package dimensions (WxDxH) | 820 x 1200 x 1120 mm |
