19" Network Cabinet - Wall Mount (Double Section Hinged Swing Out), 12U
600mm Deep, Grey, Flatpack, Max 30kg, Swings out for access to back of cabin
Model 713870EAN 766623713870
18 specifications
- TypeWall mounted rack
- Weight26.3 kg
- ColourGrey
- Rack capacity12U
- Size (imperial)48.3 cm (19")
Overview
- Type
- Wall mounted rack
- Weight
- 26.3 kg
- Colour
- Grey
- Rack capacity
- 12U
- Size (imperial)
- 48.3 cm (19")
- Brand
- Intellinet
- Category
- Rack Cabinet
- Model
- 713870
- Part number
- 713870
- EAN / UPC
- 766623713870
- Also known as
- Intellinet 19" Network Cabinet - Wall Mount (Double Section Hinged Swing Out), 12U, 600mm Deep, Grey, Flatpack, Max 30kg, Swings out for access to back of cabin
Specifications
18 specifications in 3 groups
Features
| Specification | Value |
|---|---|
| Rack capacity | 12U |
| Type | Wall mounted rack |
| Maximum weight capacity | 30 kg |
| Product colour | Grey |
| Material | Glass, SPCC |
| Frame type | Closed |
| Front door construction | Glass |
| Removable side panels | Yes |
| Side panels included | Yes |
| Key lock | Yes |
| Front door key lock | Yes |
| Certification | ANSI/EIA RS-310-D; IEC60297-2; DIN41494, Part 1; DIN41494, Part 7 |
Weight & dimensions
| Specification | Value |
|---|---|
| Size (imperial) | 48.3 cm (19") |
| Width | 540 mm |
| Depth | 600 mm |
| Height | 593 mm |
| Weight | 26.3 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85381000 |
