19" Server Cabinet - Free Standing, 36U
600x1000mm (width x depth), Black, Assembled, Max 1500kg, Multi-Point Door Lock, One Lock Per Side Panel, Us
Model 713320EAN 766623713320
21 specifications
- TypeFreestanding rack
- Weight115 kg
- ColourBlack
- Rack capacity36U
- Size (imperial)48.3 cm (19")
- Compliance certificatesRoHS
Overview
- Type
- Freestanding rack
- Weight
- 115 kg
- Colour
- Black
- Rack capacity
- 36U
- Size (imperial)
- 48.3 cm (19")
- Compliance certificates
- RoHS
- Brand
- Intellinet
- Category
- Rack Cabinet
- Model
- 713320
- Part number
- 713320
- EAN / UPC
- 766623713320
- Also known as
- Intellinet 19" Server Cabinet - Free Standing, 36U, 600x1000mm (width x depth), Black, Assembled, Max 1500kg, Multi-Point Door Lock, One Lock Per Side Panel, Us
Specifications
21 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| Rack capacity | 36U |
| Type | Freestanding rack |
| Maximum weight capacity | 1500 kg |
| Product colour | Black |
| Frame type | Closed |
| Removable side panels | Yes |
| Side panels included | Yes |
| Key lock | Yes |
| Front door key lock | Yes |
| Adjustable depth | Yes |
| Adjustable mounting rails | Yes |
| Adjustable feet | Yes |
| International Protection (IP) code | IP20 |
| Certification | UL, Gost-R |
Weight & dimensions
| Specification | Value |
|---|---|
| Size (imperial) | 48.3 cm (19") |
| Width | 600 mm |
| Depth | 1000 mm |
| Height | 1766 mm |
| Weight | 115 kg |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85381000 |
