Wall Rack Cabinet 12u Depth 450
Model AI6412Part no. 80.64.12EAN 6940533543732
26 specifications
- TypeWall mounted rack
- Weight23.8 kg
- ColourBlack
- Rack capacity12U
- Width600 mm
- Compliance certificatesRoHS
Overview
- Type
- Wall mounted rack
- Weight
- 23.8 kg
- Colour
- Black
- Rack capacity
- 12U
- Width
- 600 mm
- Compliance certificates
- RoHS
- Brand
- aiten data
- Category
- Rack Cabinet
- Model
- AI6412
- Part number
- 80.64.12
- EAN / UPC
- 6940533543732
- Also known as
- aiten data Wall Rack Cabinet 12u Depth 450
Specifications
26 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| Rack capacity | 12U |
| Type | Wall mounted rack |
| Maximum weight capacity | 60 kg |
| Product colour | Black |
| Material | SPCC |
| Frame type | Closed |
| Front door construction | Tempered glass |
| Removable side panels | Yes |
| Side panels included | Yes |
| Key lock | Yes |
| Front door key lock | Yes |
| Adjustable mounting rails | Yes |
| International Protection (IP) code | IP20 |
| Certification | ANSI/EIA RS-310-D; IEC297-2; DIN 41494; PART1; DIN 41494; PART7; ETSI; CE; ISO9001. |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 600 mm |
| Depth | 450 mm |
| Height | 620 mm |
| Weight | 23.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Screws included | Yes |
| Mounting kit | Yes |
| Package width | 680 mm |
| Package depth | 530 mm |
| Package height | 720 mm |
| Package volume | 259000 cm³ |
| Package weight | 27.4 kg |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
