ZM850-TMX TerraMax 80 PLUS GOLD PSU 850W/Full-modular 99.9% Active PFC/Single
Model ZM850-TMX TerraMax 80 PLUS GOLD PSU 850W/Full-modular 99.9% Active PFC/SinglePart no. ZM850-TMXEAN 8809213763007
17 specifications
- Weight2.6 kg
- ColourBlack
- Total power850 W
- Cabling typeFully-Modular
- Bearing technologyFDB
- Operating temperature (T-T)10 - 40 °C
Overview
- Weight
- 2.6 kg
- Colour
- Black
- Total power
- 850 W
- Cabling type
- Fully-Modular
- Bearing technology
- FDB
- Operating temperature (T-T)
- 10 - 40 °C
- Brand
- Zalman
- Category
- Power Supply Unit
- Model
- ZM850-TMX TerraMax 80 PLUS GOLD PSU 850W/Full-modular 99.9% Active PFC/Single
- Part number
- ZM850-TMX
- EAN / UPC
- 8809213763007
- Also known as
- Zalman ZM850-TMX TerraMax 80 PLUS GOLD PSU 850W/Full-modular 99.9% Active PFC/Single power supply unit Black
Specifications
17 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Total power | 850 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 12-6 A |
| Power Factor Correction (PFC) type | Active |
| Efficiency | 90% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Bearing technology | FDB |
| Mean time between failures (MTBF) | 100000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Fan diameter | 12 cm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Weight | 2.6 kg |
