ROG Loki SFX-L 850W Platinum
Model ROG Loki SFX-L 850W PlatinumPart no. 90YE00N3-B0NA00EAN 4711081722557
42 specifications
- Weight1.81 kg
- ColourBlack, Silver
- Total power850 W
- Motherboard power connector24-pin ATX
- PurposePC
- Width125 mm
Overview
- Weight
- 1.81 kg
- Colour
- Black, Silver
- Total power
- 850 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- PC
- Width
- 125 mm
- Brand
- ASUS
- Category
- Power Supply Unit
- Model
- ROG Loki SFX-L 850W Platinum
- Part number
- 90YE00N3-B0NA00
- EAN / UPC
- 4711081722557
- Also known as
- ASUS ROG Loki SFX-L 850W Platinum power supply unit 24-pin ATX Black, Silver
Specifications
42 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 850 W |
| AC input voltage | 100 - 240 V |
| Combined power (+3.3V) | 110 W |
| Combined power (+12V) | 850 W |
| Combined power (+5V) | 110 W |
| Combined power (-12V) | 9.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 70.8 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.8 A |
| Max output current (+5Vsb) | 2.5 A |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power connectors (8-pin) | 3 |
| CPU power connector (4+4 pin) | Yes |
| PCI Express connector | Yes |
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | SFX-L |
| 80 PLUS certification | 80 PLUS Platinum |
| Supported motherboard form factors | ATX |
| ATX version | 3.1 |
| Silent mode | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Silver |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Illumination | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | OPP/OVP/UVP/SCP/OCP/OTP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 125 mm |
| Depth | 125 mm |
| Height | 63.5 mm |
| Weight | 1.81 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 285 mm |
| Package depth | 190 mm |
| Package height | 100 mm |
| Package weight | 2.5 kg |
| Package type | Box |
