K70 5G

Model K70 5GPart no. T523H-2BLCA112EAN 4894461979151

138 specifications Checked today

Display17.3 cm (6.8")
Resolution720 x 1570 pixels
ProcessorSnapdragon
Memory4 GB
Storage128 GB
Camera50 MP

See all specifications

Overview

Display: 17.3 cm (6.8")
Resolution: 720 x 1570 pixels
Processor: Snapdragon
Memory: 4 GB
Storage: 128 GB
Camera: 50 MP

Brand: TCL
Category: Phone
Model: K70 5G
Part numbers: T523H-2BLCA112, T523H-2ALCA112
EAN / UPC: 4894461979151, 4894461979144
Also known as: TCL K70 5G 17.3 cm (6.8") Dual SIM Android 16.0 USB Type-C 4 GB 128 GB 5200 mAh Black

Specifications

138 specifications in 20 groups

Display

Specification	Value
Display diagonal	17.3 cm (6.8")
Display resolution	720 x 1570 pixels
Screen to body ratio	95%
Panel type	IPS
Native aspect ratio	20:9
Contrast ratio (typical)	1500:1
Maximum refresh rate	120 Hz
Display brightness	750 cd/m²
NTSC coverage (typical)	83%
Pixel density	256 ppi
Touchscreen type	Capacitive
Fingerprint resistant	Yes
Rounded display corners	Yes

Processor

Specification	Value
Processor family	Snapdragon
Processor model	4 Gen 2
Processor architecture	ARM Cortex-A78+Cortex-A55
Processor cores	8
Processor frequency	2.2 GHz
Coprocessor	Yes

Storage

Specification	Value
RAM capacity	4 GB
Internal storage capacity	128 GB
Virtual RAM (max)	8 GB
RAM type	LPDDR5
Compatible memory cards	MicroSD (TransFlash), MicroSDXC, MicroSDHC
Maximum memory card size	2 TB
Memory card slot type	Hybrid slot

Camera

Specification	Value
Rear camera type	Dual camera
Rear camera sensor size	1/2.88"
Second rear camera sensor size	1/13"
Rear camera resolution (numeric)	50 MP
Macro camera resolution (numeric)	0.08 MP
Rear camera aperture number	1.8
Rear camera pixel size	0.61 µm
Second rear camera pixel size	2.5 µm
Rear camera field of view (FOV) angle	76.8°
Rear camera lens elements	5-element lens
Front camera lens elements	4-element lens
Front camera type	Single camera
Front camera sensor size	1/4"
Front camera resolution (numeric)	8 MP
Front camera aperture number	2.05
Front camera pixel size	1.12 µm
Front camera field of view (FOV) angle	79°
Rear camera flash	Yes
Front camera flash	No
Video capture resolution (max)	1920 x 1080 pixels
Resolution at capture speed	1920x1080@30fps
Video recording modes	1080p
Auto focus	Yes
3D depth front camera	No
3D depth rear camera	No
Face detection	Yes
Camera High Dynamic Range (HDR) mode	Yes
Night mode	Yes
Panorama	Yes
AI scene recognition	Yes

Network

Specification	Value
SIM card capability	Dual SIM
Mobile network generation	5G
SIM card type	NanoSIM
3G standards	HSPA+
4G standard	LTE
5G standard	Sub6 SA/NSA, Sub6 SA, Sub6 NSA
Voice over LTE (VoLTE) supported	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac)
Bluetooth	Yes
Bluetooth Low Energy (BLE)	Yes
Bluetooth version	6.0
Frequency band	Dual-band
4G bands supported	2400,2500,2600 MHz
3G data rate (max)	42 Mbit/s
5G data rate (max)	2.3 Gbit/s
Wi-Fi Direct	Yes
Near Field Communication (NFC)	Yes

Ports & interfaces

Specification	Value
USB port	Yes
USB connector type	USB Type-C
USB version	2.0
Headphone connectivity	3.5 mm

Specification	Value
Position location	Yes
GPS (satellite)	Yes
GLONASS	Yes
Galileo	Yes
Electronic compass	Yes

Design

Specification	Value
Form factor	Bar
Product colour	Black
Colour name	Midnight Black
Protection features	Dustproof, Splash proof
Housing material	Polycarbonate (PC), Silicone

Performance

Specification	Value
Video call	Yes
Fast charging	Yes
Wireless charging	No
AI control	Yes
Fingerprint reader	Yes
Face recognition	Yes
Speakerphone	Yes
Voice commands	Yes
Vibrating alert	Yes

Multimedia

Specification	Value
Number of microphones	1
Speakers	stereo
Audio formats supported	AAC, HE-AAC, HE-AAC v2, AWB, AMR, MIDI, MP3, OGG, Vorbis, WAV, G.711 A-law, G.711 μ-law, FLAC, OPUS
Video formats supported	MPEG2, MPEG4, H.264, H.263, H.265, VP8, VP9

Software

Specification	Value
Platform	Android
Operating system installed	Android 16.0

Battery

Specification	Value
Battery capacity	5200 mAh
Battery technology	Lithium-Ion (Li-Ion)
Battery recharge time	2.3 h
Battery endurance in cycles	1000

Power

Specification	Value
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes
USB Type-C required charging power (max)	18 W
USB Type-C required charging power (min)	1.5 W

Endurance

Specification	Value
Energy efficiency class	A
Energy efficiency scale	A to G
Battery endurance per cycle	3499 min
Repeated free fall reliability class	A
Repairability class	B
International Protection (IP) code	IP64

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Proximity sensor	Yes

Weight & dimensions

Specification	Value
Weight	197 g
Width	79.5 mm
Depth	8.26 mm
Height	168.1 mm

Packaging data

Specification	Value
Package width	95 mm
Package depth	66 mm
Package height	185 mm
Package weight	400 g

Packaging content

Specification	Value
AC adapter included	No
Quick start guide	Yes
Cables included	USB Type-C
Protective case	Yes
SIM card ejector pin	Yes

Certificates

Specification	Value
Compliance certificates	TÜV SÜD mark
Digital Living Network Alliance (DLNA) certified	No

Other features

Specification	Value
Ringer type	MP3
Warranty period	2 year(s)
