Samsung Galaxy SM-M515F/DSN

Galaxy SM-M515F/DSN

17 cm (6.7") Dual SIM 4G USB Type-C 6 GB 128 GB 7000 mAh Black

Model SM-M515F/DSNPart no. SM-M515FZKDEUBEAN 8806090713538

84 specifications Checked today

Display17 cm (6.7")
Resolution2400 x 1080 pixels
Memory6 GB
Storage128 GB
Camera64 MP
Battery7000 mAh

See all specifications

Overview

Display: 17 cm (6.7")
Resolution: 2400 x 1080 pixels
Memory: 6 GB
Storage: 128 GB
Camera: 64 MP
Battery: 7000 mAh

Brand: Samsung
Category: Phone
Model: SM-M515F/DSN
Part numbers: SM-M515FZKDEUB, SM-M515FZWDEUB
EAN / UPC: 8806090713538, 8806090713507
Also known as: Samsung Galaxy SM-M515F/DSN 17 cm (6.7") Dual SIM 4G USB Type-C 6 GB 128 GB 7000 mAh Black

Specifications

84 specifications in 20 groups

Display

Specification	Value
Display diagonal	17 cm (6.7")
Display resolution	2400 x 1080 pixels
Screen shape	Flat
Display technology marketing name	Super AMOLED Plus
Panel type	OLED
Display number of colours	16 million colours

Processor

Specification	Value
Processor cores	8
Processor frequency	2.2 GHz
Coprocessor frequency	1.8 GHz

Storage

Specification	Value
RAM capacity	6 GB
Internal storage capacity	128 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB

Camera

Specification	Value
Rear camera type	Quad camera
Rear camera resolution (numeric)	64 MP
Second rear camera resolution (numeric)	12 MP
Third rear camera resolution (numeric)	5 MP
Fourth rear camera resolution (numeric)	5 MP
Rear camera aperture number	1.8
Second rear camera aperture number	2.2
Third rear camera aperture number	2.4
Fourth rear camera aperture number	2.4
Digital zoom	8x
Front camera type	Single camera
Front camera resolution (numeric)	32 MP
Front camera aperture number	2.2
Rear camera flash	Yes
Video capture resolution (max)	3840 x 2160 pixels
Maximum frame rate	240 fps

Network

Specification	Value
SIM card capability	Dual SIM
Mobile network generation	4G
SIM card type	NanoSIM
3G standards	UMTS
4G standard	LTE-TDD & LTE-FDD
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth	Yes
Bluetooth version	5.0
3G bands supported	850,900,1900,2100 MHz
4G bands supported	700,800,850,900,1800,1900,2100,2300,2500,2600 MHz
Wi-Fi Direct	Yes
Near Field Communication (NFC)	Yes

Subscription

Specification	Value
Subscription type	No subscription

Ports & interfaces

Specification	Value
USB port	Yes
USB connector type	USB Type-C
USB version	2.0
Headphone connectivity	3.5 mm

Messaging

Specification	Value
Short Message Service (SMS)	Yes
Multimedia Messaging Service (MMS)	Yes

Design

Specification	Value
Form factor	Bar
Product colour	Black

Performance

Specification	Value
Video call	Yes
Fingerprint reader	Yes

Multimedia

Specification	Value
FM radio	No
Audio formats supported	3GA, AAC, AMR, AWB, FLAC, IMY, M4A, Mid, MIDI, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, WMA, XMF
Video formats supported	3G2, 3GP, ASF, AVI, FLV, M4V, MKV, MP4, WEBM, WMV

Software

Specification	Value
Platform	Android
App distribution platform	Google Play

Battery

Specification	Value
Battery capacity	7000 mAh
Talk time (4G) (max)	64 h
Browsing time (Wi-Fi) (max)	24 h
Browsing time (4G) (max)	23 h
Continuous audio playback time	182 h
Continuous video playback time (max)	34 h

Endurance

Specification	Value
Repairability index	5.6

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Proximity sensor	Yes
Gyroscope	Yes
Magnetic sensor	Yes

Weight & dimensions

Specification	Value
Weight	213 g
Width	76.3 mm
Depth	9.5 mm
Height	163.9 mm

Packaging content

Specification	Value
Quick start guide	Yes

Specific absorption rate (SAR)

Specification	Value
Head SAR (EU)	0.609 W/kg
Body SAR (EU)	1.446 W/kg
Extremities SAR (EU)	2.44 W/kg

Other features

Specification	Value
Touchscreen	Yes
