Galaxy S20+ 5G SM-G986 17 cm (6.7") Single SIM Android 10 USB Type-C 12 GB 128 GB 4500 mAh Grey
Model SM-G986Part no. 0TSAGAS2OU7018EAN 8032325296068
136 specifications Checked today
- Display17 cm (6.7")
- Resolution3200 x 1440 pixels
- ProcessorSamsung Exynos
- Memory12 GB
- Storage128 GB
- Camera12 MP
Overview
- Display
- 17 cm (6.7")
- Resolution
- 3200 x 1440 pixels
- Processor
- Samsung Exynos
- Memory
- 12 GB
- Storage
- 128 GB
- Camera
- 12 MP
- Brand
- Samsung
- Category
- Phone
- Model
- SM-G986
- Part numbers
- 0TSAGAS2OU7018, 0TSAGAS2OU7019
- EAN / UPC
- 8032325296068, 8032325296075
- Also known as
- Samsung Galaxy S20+ 5G SM-G986 17 cm (6.7") Single SIM Android 10 USB Type-C 12 GB 128 GB 4500 mAh Grey
Specifications
136 specifications in 19 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 17 cm (6.7") |
| Display resolution | 3200 x 1440 pixels |
| Screen shape | Curved edge screen |
| Display technology marketing name | Dynamic AMOLED 2X |
| Panel type | OLED |
| Display glass type | Gorilla Glass |
| Gorilla Glass version | Gorilla Glass 6 |
| Display number of colours | 16.78 million colours |
| Native aspect ratio | 20:9 |
| Maximum refresh rate | 120 Hz |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10+ (HDR10 Plus) |
| Pixel density | 525 ppi |
| Touchscreen type | Capacitive |
| Rounded display corners | Yes |
Processor
| Specification | Value |
|---|---|
| Processor family | Samsung Exynos |
| Processor model | 990 |
| Processor cores | 8 |
| Processor frequency | 2.7 GHz |
| Coprocessor | Yes |
| Coprocessor frequency | 2.5 GHz |
Storage
| Specification | Value |
|---|---|
| RAM capacity | 12 GB |
| Internal storage capacity | 128 GB |
| RAM type | LPDDR5 |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 1 TB |
| USB mass storage | Yes |
Camera
| Specification | Value |
|---|---|
| Rear camera type | Quad camera |
| Rear camera sensor size | 1/1.76" |
| Rear camera resolution (numeric) | 12 MP |
| Second rear camera resolution (numeric) | 12 MP |
| Third rear camera resolution (numeric) | 64 MP |
| Rear camera resolution | 9248 x 6936 pixels |
| Rear camera aperture number | 1.8 |
| Second rear camera aperture number | 2.2 |
| Third rear camera aperture number | 2 |
| Fourth rear camera aperture number | 1 |
| Rear camera pixel size | 1.8 µm |
| Second rear camera pixel size | 1.4 µm |
| Third rear camera pixel size | 0.8 µm |
| Rear camera field of view (FOV) angle | 79° |
| Second rear camera field of view (FOV) angle | 120° |
| Third rear camera field of view (FOV) angle | 76° |
| Optical zoom | 3x |
| Digital zoom | 30x |
| Front camera type | Single camera |
| Front camera resolution (numeric) | 10 MP |
| Front camera aperture number | 2.2 |
| Front camera pixel size | 1.22 µm |
| Front camera field of view (FOV) angle | 80° |
| Rear camera flash | Yes |
| Flash type | LED |
| Video capture resolution (max) | 7680 x 4320 pixels |
| Maximum frame rate | 960 fps |
| Resolution at capture speed | 1280x720@30fps, 1280x720@960fps, 1920x1080@240fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps, 3840x2160@60fps |
| Video recording modes | 720p, 1080p, 2160p |
| Auto focus | Yes |
| 3D depth rear camera | Yes |
| Video stabilizer | Yes |
| Image stabilizer | Yes |
| Geotagging | Yes |
| Multi-shot | Yes |
| Night mode | Yes |
| Self-timer | Yes |
Network
| Specification | Value |
|---|---|
| SIM card capability | Single SIM |
| Mobile network generation | 5G |
| SIM card type | NanoSIM |
| 3G standards | HSDPA, HSPA+, HSUPA, UMTS |
| 4G standard | LTE |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| MIMO | Yes |
| Tethering (modem-mode) | Yes |
| Wi-Fi Direct | Yes |
| Near Field Communication (NFC) | Yes |
Subscription
| Specification | Value |
|---|---|
| Subscription type | No subscription |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB connector type | USB Type-C |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| ANT+ enabled | Yes |
Messaging
| Specification | Value |
|---|---|
| Short Message Service (SMS) | Yes |
| Multimedia Messaging Service (MMS) | Yes |
| Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Bar |
| Product colour | Grey |
| Colour name | Cosmic Grey |
| Protection features | Dust resistant, Water resistant |
Performance
| Specification | Value |
|---|---|
| Video call | Yes |
| Fast charging | Yes |
| Wireless charging | Yes |
| Graphics card | Mali-G77 MP11 |
| Fingerprint reader | Yes |
| Face recognition | Yes |
| Speakerphone | Yes |
| USB On-The-Go support | Yes |
| Voice commands | Yes |
| Vibrating alert | Yes |
Multimedia
| Specification | Value |
|---|---|
| Audio system | Dolby Atmos |
| Speakers | stereo |
| Supported video modes | 720p, 1080p, 2160p, 4320p |
| Audio formats supported | 3GA, AAC, AMR, APE, AWB, DFF, DSF, FLAC, IMY, M4A, Mid, MIDI, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, WMA, XMF |
| Video formats supported | 3G2, 3GP, ASF, AVI, FLV, M4V, MKV, MP4, WEBM, WMV |
Software
| Specification | Value |
|---|---|
| Platform | Android |
| Operating system installed | Android 10 |
| App distribution platform | Google Play |
| Google applications | Gmail, Google Chrome, Google Play, YouTube |
| Virtual assistant | Samsung Bixby |
Battery
| Specification | Value |
|---|---|
| Battery capacity | 4500 mAh |
| Wireless Power Share | Yes |
Endurance
| Specification | Value |
|---|---|
| Repairability index | 5.9 |
| International Protection (IP) code | IP68 |
Sensors
| Specification | Value |
|---|---|
| Accelerometer | Yes |
| Ambient light sensor | Yes |
| Proximity sensor | Yes |
| Gyroscope | Yes |
| Barometer | Yes |
| Geomagnetic sensor | Yes |
| Hall sensor | Yes |
| Orientation sensor | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 186 g |
| Width | 73.7 mm |
| Depth | 7.8 mm |
| Height | 161.9 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
| Cables included | USB Type-C |
| SIM card ejector pin | Yes |
Other features
| Specification | Value |
|---|---|
| Touchscreen | Yes |
