Samsung Galaxy Z Fold5 SM-F946B
Samsung

Galaxy Z Fold5 SM-F946B

19.3 cm (7.6") Dual SIM Android 13 5G USB Type-C 12 GB 1 TB 4400 mAh Blue

Model SM-F946BPart no. SM-F946BLK256EAN 8806095012469

134 specifications Checked today
  • Display19.3 cm (7.6")
  • Resolution2176 x 1812 pixels
  • ProcessorSnapdragon
  • Memory12 GB
  • Storage1 TB
  • Camera50 MP
See all specifications

Overview

Display
19.3 cm (7.6")
Resolution
2176 x 1812 pixels
Processor
Snapdragon
Memory
12 GB
Storage
1 TB
Camera
50 MP
Brand
Samsung
Category
Phone
Model
SM-F946B
Part numbers
SM-F946BLK256, SM-F946BLBCEUB-M, SM-F946BZECEUB-M, SM-F946BZKCEUB-M, SM-F946BLBAATS, SM-F946BLBEATS +34 more
EAN / UPC
8806095012469, 8806095012476, 8806095012452, 8806095012414 +25 more
Also known as
Samsung Galaxy Z Fold5 SM-F946B 19.3 cm (7.6") Dual SIM Android 13 5G USB Type-C 12 GB 1 TB 4400 mAh Blue

Specifications

134 specifications in 15 groups

Display

Display diagonal19.3 cm (7.6")
Display resolution2176 x 1812 pixels
Screen shapeFlat
Display technology marketing nameDynamic AMOLED 2X
Panel typeOLED
Display glass typeGorilla Glass
Gorilla Glass versionGorilla Glass Victus 2
Display number of colours16 million colours
Maximum refresh rate120 Hz
Display brightness1200 cd/m²
Maximum display brightness (Outdoor)1750 cd/m²
Brand specific technologiesAlways-on display
Pixel density374 ppi
Rounded display cornersYes
Second displayYes
Second display diagonal15.8 cm (6.2")
Second display brightness1000 cd/m²
Second display resolution2316 x 904 pixels
Second display typeDynamic AMOLED 2X
Second display refresh rate120 Hz

Processor

Processor familySnapdragon
Processor model8 Gen 2
Processor cores8
Processor boost frequency3.36 GHz

Storage

RAM capacity12 GB
Internal storage capacity1 TB

Camera

Rear camera typeTriple camera
Rear camera sensor size1/1.56"
Second rear camera sensor size1/3.21"
Third rear camera sensor size1/3.94"
Rear camera resolution (numeric)50 MP
Second rear camera resolution (numeric)12 MP
Third rear camera resolution (numeric)10 MP
Rear camera resolution6120 x 8160 pixels
Rear camera aperture number1.8
Second rear camera aperture number2.2
Third rear camera aperture number2.4
Rear camera pixel size1 µm
Second rear camera pixel size1.12 µm
Third rear camera pixel size1 µm
Rear camera field of view (FOV) angle85°
Second rear camera field of view (FOV) angle123°
Third rear camera field of view (FOV) angle36°
Optical zoom3x
Digital zoom30x
Front camera typeDual camera
Front camera sensor size1/3.24"
Front camera resolution (numeric)10 MP
Second front camera resolution (numeric)4 MP
Front camera aperture number2.2
Second front camera aperture number1.8
Front camera pixel size1.22 µm
Second front camera pixel size2 µm
Front camera field of view (FOV) angle85°
Second front camera field of view (FOV) angle80°
Rear camera flashYes
Flash typeLED
Video capture resolution (max)4320 x 7680 pixels
Maximum frame rate960 fps
Resolution at capture speed1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps, 3840x2160@60fps, 7680x4320@30fps
Video recording modes720p, 1080p, 2160p, 4320p
Auto focusYes
Time lapse modeYes
Image stabilizerYes
Image stabilizer typeOptical Image Stabilization (OIS)
Night modeYes
PanoramaYes
Portrait modeYes

Network

SIM card capabilityDual SIM
Mobile network generation5G
SIM card typeNanoSIM + eSIM
3G standardsUMTS, WCDMA
4G standardLTE-TDD & LTE-FDD
5G standardSub6 FDD, Sub6 TDD
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
BluetoothYes
Bluetooth version5.3
3G bands supported850,900,1900,2100 MHz
4G bands supported700,800,850,900,1500,1800,1900,2100,2300,2500,2600 MHz
5G bands supported700,800,850,900,1800,1900,2100,2300,2500,2600,3500,3700 MHz
MIMOYes
Modulation1024-QAM
Wi-Fi DirectYes
Near Field Communication (NFC)Yes

Ports & interfaces

USB portYes
USB connector typeUSB Type-C
USB version3.2 Gen 1 (3.1 Gen 1)
Headphone connectivityUSB Type-C

Navigation

Position locationYes
GPS (satellite)Yes
BeiDouYes
GLONASSYes
GalileoYes
Quasi-Zenith Satellite System (QZSS)Yes

Design

Form factorFold
Product colourBlue
Colour nameIcy Blue
Protection featuresWater resistant
Housing materialAluminium

Performance

Fast chargingYes
Wireless chargingYes
Fingerprint readerYes
Face recognitionYes
USB On-The-Go supportYes

Multimedia

Audio systemDolby Atmos
EqualizerYes
Speakersstereo
Audio formats supported3GA, AAC, AMR, APE, AWB, DFF, DSF, FLAC, IMY, M4A, Mid, MIDI, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, XMF
Video formats supported3G2, 3GP, AVI, FLV, M4V, MKV, MP4, WEBM

Software

PlatformAndroid
Operating system installedAndroid 13

Battery

Battery capacity4400 mAh
Talk time (4G) (max)40 h
Browsing time (Wi-Fi) (max)18 h
Browsing time (4G) (max)17 h
Wireless audio playback time73 h
Wireless video playback time21 h

Endurance

Repairability index8
International Protection (IP) codeIPX8

Sensors

AccelerometerYes
Ambient light sensorYes
Proximity sensorYes
GyroscopeYes
BarometerYes
Geomagnetic sensorYes
Hall sensorYes

Weight & dimensions

Weight253 g
Width129.9 mm
Depth6.1 mm
Height154.9 mm
Folded width6.71 cm
Folded depth1.34 cm
Folded height15.5 cm
