Samsung SM-F766W 17.3 cm (6.8") Dual SIM Android 16.0 5G USB Type-C 12 GB 256 GB 4300 mAh Blue

SM-F766W 17.3 cm (6.8") Dual SIM Android 16.0 5G USB Type-C 12 GB 256 GB 4300 mAh Blue

Model SM-F766WPart no. SM-F766WDBAXACEAN 198957111884

107 specifications Checked today

Display17.3 cm (6.8")
Resolution2520 x 1080 pixels
ProcessorSamsung Exynos
Memory12 GB
Storage256 GB
Camera50 MP

See all specifications

Overview

Display: 17.3 cm (6.8")
Resolution: 2520 x 1080 pixels
Processor: Samsung Exynos
Memory: 12 GB
Storage: 256 GB
Camera: 50 MP

Brand: Samsung
Category: Phone
Model: SM-F766W
Part numbers: SM-F766WDBAXAC, SM-F766WZRAXAC
EAN / UPC: 198957111884, 198957111648
Also known as: Samsung SM-F766W 17.3 cm (6.8") Dual SIM Android 16.0 5G USB Type-C 12 GB 256 GB 4300 mAh Blue

Specifications

107 specifications in 17 groups

Display

Specification	Value
Display diagonal	17.3 cm (6.8")
Display resolution	2520 x 1080 pixels
Screen shape	Flat
Display technology marketing name	Dynamic AMOLED 2X
Panel type	AMOLED
Display glass type	Corning Glass
Gorilla Glass version	Gorilla Glass Victus 2
Display number of colours	16 million colours
Maximum refresh rate	120 Hz
Second display diagonal	10.2 cm (4")
Second display resolution	1048 x 948 pixels
Second display type	Dynamic AMOLED 2X
Second display Gorilla Glass version	Gorilla Glass Victus 2
Second display refresh rate	120 Hz

Processor

Specification	Value
Processor family	Samsung Exynos
Processor model	2500
Processor cores	10
Processor boost frequency	3.3 GHz

Storage

Specification	Value
RAM capacity	12 GB
Internal storage capacity	256 GB
User memory	229 GB

Camera

Specification	Value
Rear camera type	Dual camera
Rear camera resolution (numeric)	50 MP
Second rear camera resolution (numeric)	12 MP
Rear camera aperture number	1.8
Second rear camera aperture number	2.2
Digital zoom	10x
Front camera type	Single camera
Front camera resolution (numeric)	10 MP
Front camera aperture number	2.2
Rear camera flash	Yes
Video capture resolution (max)	3840 x 2160 pixels
Maximum frame rate	240 fps
Resolution at capture speed	3840x2160@30fps
Auto focus	Yes
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Night mode	Yes
Slow motion mode	Yes
Slow motion rate	240fps @FHD, 120fps @FHD

Network

Specification	Value
SIM card capability	Dual SIM
Mobile network generation	5G
SIM card type	NanoSIM + eSIM
3G standards	UMTS
4G standard	LTE-TDD & LTE-FDD
5G standard	Sub6 TDD, Sub6 FDD
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth	Yes
Bluetooth version	5.4
Frequency band	Tri-band
MIMO	Yes
Modulation	4096-QAM
Wi-Fi Direct	Yes
Near Field Communication (NFC)	Yes

Ports & interfaces

Specification	Value
USB connector type	USB Type-C
USB version	3.2 Gen 1 (3.1 Gen 1)

Design

Specification	Value
Form factor	Flip
Product colour	Blue
Colour name	Blue Shadow

Performance

Specification	Value
Fast charging	Yes
Wireless charging	Yes
Wireless charging power	15 W
Fingerprint reader	Yes
Country of origin	Vietnam

Multimedia

Specification	Value
Speakers	stereo
Audio formats supported	MP3, M4A, 3GA, AAC, OGG, OGA, WAV, AMR, AWB, FLAC, Mid, MIDI, XMF, MXMF, IMY, RTTTL, RTX, OTA, DFF, DSF, APE
Video formats supported	MP4, M4V, 3GP, 3G2, AVI, FLV, MKV, WEBM

Software

Specification	Value
Platform	Android
Operating system installed	Android 16.0
User interface (UI)	One UI 8
Security updates end date	31 July 2032

Battery

Specification	Value
Battery capacity	4300 mAh
Battery endurance in cycles	2000
Wireless video playback time	31 h

Power

Specification	Value
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes
USB Type-C required charging power (max)	25 W
USB Type-C required charging power (min)	15 W

Endurance

Specification	Value
Energy efficiency class	B
Energy efficiency scale	A to G
Battery endurance per cycle	2524 min
Repeated free fall reliability class	A
Repairability class	C
Repairability index	2.9
International Protection (IP) code	IP48

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Proximity sensor	Yes
Gyroscope	Yes
Barometer	Yes
Geomagnetic sensor	Yes
Hall sensor	Yes

Weight & dimensions

Specification	Value
Weight	188 g
Width	75.2 mm
Depth	6.5 mm
Height	166.7 mm
Folded depth	1.37 cm
Folded height	8.55 cm

Packaging content

Specification	Value
AC adapter included	No
Cables included	USB Type-C to USB Type-C
SIM card ejector pin	Yes
