ASUS ZenFone Max Plus ZB570TL-4G035WW

ZenFone Max Plus ZB570TL-4G035WW

14.5 cm (5.7") Dual SIM Android 7.0 4G Micro-USB 3 GB 32 GB 4130 mAh Black, Gold

Model ZB570TL-4G035WWPart no. 90AX0183-M00490EAN 4712900900514

141 specifications Checked today

Display14.5 cm (5.7")
Resolution2160 x 1080 pixels
ProcessorMediaTek
Memory3 GB
Storage32 GB
Camera16 MP

See all specifications

Overview

Display: 14.5 cm (5.7")
Resolution: 2160 x 1080 pixels
Processor: MediaTek
Memory: 3 GB
Storage: 32 GB
Camera: 16 MP

Brand: ASUS
Category: Phone
Model: ZB570TL-4G035WW
Part numbers: 90AX0183-M00490, 90AX0183-M00840, 90AX0183-M01540
EAN / UPC: 4712900900514, 4712900938661
Also known as: ASUS ZenFone Max Plus ZB570TL-4G035WW 14.5 cm (5.7") Dual SIM Android 7.0 4G Micro-USB 3 GB 32 GB 4130 mAh Black, Gold

Specifications

141 specifications in 22 groups

Display

Specification	Value
Display diagonal	14.5 cm (5.7")
Display resolution	2160 x 1080 pixels
Screen shape	Curved edge screen
Panel type	IPS
Native aspect ratio	18:9
Touch technology	Multi-touch
Touchscreen type	Capacitive
Rounded display corners	Yes
Second display	No

Processor

Specification	Value
Processor family	MediaTek
Processor model	MT6750T
Processor cores	8
Processor frequency	1.5 GHz
64-bit computing	Yes

Storage

Specification	Value
RAM capacity	3 GB
Internal storage capacity	32 GB
RAM type	LPDDR3
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	256 GB
Memory card hot swapping	Yes
Memory card slot type	Hybrid slot
USB mass storage	Yes

Camera

Specification	Value
Rear camera type	Dual camera
Rear camera resolution (numeric)	16 MP
Second rear camera resolution (numeric)	8 MP
Rear camera aperture number	2
Front camera type	Single camera
Front camera resolution (numeric)	8 MP
Front camera aperture number	2
Rear camera flash	Yes
Flash type	LED
Maximum frame rate	30 fps
Resolution at capture speed	1920x1080@30fps
Video recording modes	720p, 1080p
Auto focus	Yes
Zoom capability	Yes
Face detection	Yes
Video recording	Yes
Time lapse mode	Yes
Video stabilizer	Yes
Image stabilizer	Yes
Geotagging	Yes
Night mode	Yes
Self-timer	Yes
Smile detection	Yes

Network

Specification	Value
SIM card capability	Dual SIM
Mobile network generation	4G
SIM card type	NanoSIM
SIM card hot swapping	Yes
2G standards	Edge, GPRS, GSM
3G standards	DC-HSPA+, WCDMA
4G standard	LTE-TDD
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth	Yes
Bluetooth version	4.0
Bluetooth profiles	A2DP
2G bands (primary SIM)	850,900,1800,1900 MHz
2G bands (secondary SIM)	850,900,1800,1900 MHz
3G bands supported	850,900,2100 MHz
4G bands supported	850,900,1800,2100,2600 MHz
Tethering (modem-mode)	Yes
Wi-Fi Direct	Yes
HotKnot	Yes

Subscription

Specification	Value
Subscription type	No subscription

Ports & interfaces

Specification	Value
USB port	Yes
USB connector type	Micro-USB
HDMI ports quantity	0
Headphone connectivity	3.5 mm

Messaging

Specification	Value
Short Message Service (SMS)	Yes
Multimedia Messaging Service (MMS)	Yes
Instant messaging (IM)	Yes
Chat	Yes
E-mail	Yes

Design

Specification	Value
Form factor	Bar
Product colour	Black, Gold
Colour name	Sunlight Gold
Housing material	Metal

Performance

Specification	Value
Video call	Yes
Fast charging	Yes
Graphics card	Mali T860 MP2
Fingerprint reader	Yes
Flight mode	Yes
Microphone mute	Yes
Personal info management (PIM)	Alarm clock, Blacklist, Calculator, Calendar, Countdown timer, Events reminder, File manager, Notes, Recorder, Stopwatch, To-do list
Personalization	Menu, Ringtones, Shortcuts, Wallpaper, Widgets
Speakerphone	Yes
Support for contact groups	Yes
Themes	Wallpapers
USB On-The-Go support	Yes
Voice commands	Yes
Voice dialling	Yes
Vibrating alert	Yes

Multimedia

Specification	Value
FM radio	Yes
Equalizer	Yes
Speakers	stereo
Supported video modes	720p, 960p, 1080p

Call management

Specification	Value
Auto-redialing	Yes
Call blocking	Yes
Call divert	Yes
Call hold	Yes
Call timer	Yes
Call waiting	Yes
Caller ID	Yes
Conference call	Yes
Speed dialling	Yes

Software

Specification	Value
Platform	Android
Operating system installed	Android 7.0
App distribution platform	Google Play
Exchange support	Yes
Google applications	Gmail, Google Calendar, Google Chrome, Google Maps, Google Music, Google Play, Google Voice Search

Battery

Specification	Value
Battery capacity	4130 mAh
Removable battery	No
Talk time (3G) (max)	26 h
Standby time (4G) (max)	26 h
Browsing time (Wi-Fi) (max)	21 h
Continuous video playback time (max)	13 h

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Proximity sensor	Yes
Gyroscope	Yes
Orientation sensor	Yes

Weight & dimensions

Specification	Value
Weight	160 g
Width	73 mm
Depth	8.8 mm
Height	152.6 mm

Packaging content

Specification	Value
AC adapter included	Yes
Quick start guide	Yes
Warranty card	Yes
Cables included	Micro-USB, OTG
Manual	Yes

Certificates

Specification	Value
Certification	CE

Specific absorption rate (SAR)

Specification	Value
Head SAR (EU)	0.41 W/kg
Body SAR (EU)	1.2 W/kg

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C

Other features

Specification	Value
Touchscreen	Yes
